LX Navigation Zeus User Manual page 62

Extended TP data is available in the lower section of the first subpage. The upper part of the display (1
subpage) is vertical terrain profile.
To activate the screen buttons for the TP options the Zoom
rotary knob should be pressed when on TP screen (not at
APT or TSK).
Up to three turn-point files can be active at the same
time. The activation should be performed under
Setup>Transfer. Turn-points included in all three files will
be available for navigation. The first file (TP/TSK/Eos) will
import tasks. Imported tasks are available in TSK
navigation mode.
3.4.1.1 Edit TP
Press Zoom rotary knob on main TP navigation screen,
select screen button Edit TP and a new window called Edit
turn point will open.
Note!
LX Zeus v4.0.2
st
61 | P a g e
