LX Navigation Zeus User Manual page 63

3.4.1.2 Create User turnpoints
User turn-points are turn-points that are created by the
pilot on LX Zeus
Auto TP
If Auto TP is selected, a user TP will be created, with the
current position and the current time as its name. To edit
an Auto created TP use the Edit TP function.
By hand
Press the Zoom rotary knob on the main TP navigation
page and a menu with screen buttons will open. Press Add
TP.
The following information can be entered:

Name.

Details (not obligatory).

Type (grass, field, tower...).

Longitude, Latitude.

Elevation.
Other input fields may not be highlighted due to the turn-point type being added. Finish the process with
Add turn-point.
Type option offers plenty of turn-point designators. The designator defines the symbol that will appear
on the display. A landable point will be shown on the list in NEAR function.
Note!
LX Zeus v4.0.2
62 | P a g e
