2.2.10
All settings connected to Airspace
management are available in this menu.
Hide above airplane option will remove airspace
sections which are higher than the setting. This will
reduce the clutter on the graphic page significantly.
1000
m
Example of Hide airspace above:
•
The maximum vertical and horizontal distance
to which airspace in Airspace info box on map
is displayed can be set. If there isn't any
airspace that fulfil these conditions the
Airspace info box will not appear
•
Hide above QNH altitude to disable airspace that is above set QNH altitude
•
Audio warnings (on vario) when airspace warning appears on the LX Zeus can be dismissed
(dismiss buttons)
Default warnings for airspace are set to 2 km horizontally and 100 m vertically but these warning settings
can be adjusted. Warning timeout at takeoff is pre-set to 5 minutes, which means, that during the first 5
minutes after takeoff there will not be any airspace warnings.
Show on zoom, defines appearance of particular airspace sections on the display. Appearance is
connected to zoom. Airspace warning can be set as active ( ) or as not active ( ).

Airspace

Note!
