o Connect condition with (if there is more than one condition, select what conditions are
to be connected with AND or OR)
o When your condition is complete select "Add cond" (if you want to remove it, select
"Clear cond").
o When finished select Exit
It is possible to edit all user-defined warnings, and to delete them.
Other useful information
User (pilot) settings can also be saved to the USB stick and importing a user done by pressing the buttons:
Import user (VARIO/FLARM) and Save user (TSK/MOVE). There is also an option to a set password to each
pilot profile to prevent other pilots flying with the same unit and changing the pilot settings (this function
was specially developed for flying in clubs). After a press on clear password the password will be removed.
To delete a user, simply select delete user.
2.2.3
This menu defines audio configuration. The
audio generator is a part of the vario unit
(USB D 60), but settings are stored in LX
Zeus. Audio settings do not appear if there
is a LX Eos connected to the system.
Instead there is a LX Eos icon where the LX Eos can be set
up. For more information please check the LX Eos chapter.
Speed command mode:
• Defines audio in SC. The most commonly used
setting is both which means SC will beep in both positive
and negative deflections
Speed command volume:
• Defines audio volume in SC; it may be increased or
decreased
Vario tone:
• Defines audio in vario mode; the frequencies can be adjusted and also the types of audio; use
Test vario after adjustment
Alarm: The audio generator is also capable of generating some alarms (warnings) combining two
frequencies. Set frequencies and time intervals and use Test to check.

Audio

LX Zeus v4.0.2
