6.1.6 Tips and Tricks

*
*
*
*
*
*
Table 6.1 Tips and tricks
6.1.7 Quick Transfer of Parameter Settings when Using GLCP
6 6
Once the set-up of a frequency converter is complete, it is recommended to store (backup) the parameter settings in the
GLCP or on a PC via MCT 10 Set-up Software Tool.
WARNING
Stop the motor before performing any of these operations.
Data storage in LCP:
1. Go to 0-50 LCP Copy
2. Press the [OK] key
3. Select "All to LCP"
4. Press the [OK] key
All parameter settings are now stored in the GLCP indicated by the progress bar. When 100% is reached, press [OK].
The GLCP can now be connected to another frequency converter and the parameter settings copied to this frequency
converter.
Data transfer from LCP to Frequency converter:
1. Go to 0-50 LCP Copy
2. Press the [OK] key
3. Select "All from LCP"
4. Press the [OK] key
The parameter settings stored in the GLCP are now transferred to the frequency converter indicated by the progress bar.
When 100% is reached, press [OK].
6.1.8 Initialisation to Default Settings
There are two ways to initialise the frequency converter to default: Recommended initialisation and manual initialisation.
Please be aware that they have different impact according to the below description.
Recommended initialisation (via 14-22 Operation Mode)
1. Select 14-22 Operation Mode
2. Press [OK]
3. Select "Initialisation" (for NLCP select "2")
4. Press [OK]
52
ADAP-KOOL
For the majority of ADAP-KOOL applications the Quick Menu, Quick Set-up and Function Set-up provides the simplest
and quickest access to all the typical parameters required.
Whenever possible, performing an AMA, will ensure best shaft performance
Contrast of the display can be adjusted by pressing [Status] and [▲] for darker display or by pressing [Status] and [▼]
for brighter dispaly
Under [Quick Menu] and [Changes Made] all parameters that have been changed from factory settings are displayed
Press and hold [Main Menu] key for 3 seconds for access to any parameter
For service purposes it is recommended to copy all parameters to the LCP, see par 0-50 for further information
®
Drive Operating Instructions
®
MG.11.L4.02 - ADAP-KOOL Drive
