Electrical Installation
5.1.3 Fuses
Branch circuit protection
In order to protect the installation against electrical and fire hazard, all branch circuits in an installation, switch gear,
machines etc., must be shortcircuit and overcurrent protected according to the national/international regulations.
Short circuit protection
The frequency converter must be protected against short-circuit to avoid electrical or fire hazard. Danfoss recommends
using the fuses mentioned in tables 4.3 and 4.4 to protect service personnel or other equipment in case of an internal
failure in the unit. The frequency converter provides full short circuit protection in case of a short-circuit on the motor
output.
5 5
Over-current protection
Provide overload protection to avoid fire hazard due to overheating of the cables in the installation. Over current protection
must always be carried out according to national regulations. The frequency converter is equipped with an internal over
current protection that can be used for upstream overload protection (UL-applications excluded). See ADAP-KOOL
AKD102 Programming Guide, par. 4-18. Fuses must be designed for protection in a circuit capable of supplying a maximum
of 100,000 A
rms
Non UL compliance
If UL/cUL is not to be complied with, Danfoss recommends using the fuses mentioned in table 4.2, which will ensure
compliance with EN50178:
In case of malfunction, not following the recommendation may result in unnecessary damage to the frequency converter.
Frequency
converter
200-240 V
K25-K75
1K1-1K5
2K2
3K0
3K7
5K5
7K5
11K
15K
18K5
22K
30K
37K
45K
380-480 V
K37-1K5
2K2-3K0
4K0-5K5
7K5
11K-15K
18K
22K
30K
37K
45K
55K
75K
90K
Table 5.3 Non UL fuses 200 V to 480 V
1) Max. fuses - see national/international regulations for selecting an applicable fuse size.
*170M fuses from Bussmann shown use the -/80 visual indicator, -TN/80 Type T, -/110 or TN/110 Type T indicator fuses of
the same size and amperage may be substituted for external use.
28
ADAP-KOOL
(symmetrical), 500 V/600 V maximum.
Max. fuse size
®
Drive Operating Instructions
1
10A
1
16A
1
25A
1
25A
1
35A
1
50A
1
63A
1
63A
1
80A
1
125A
1
125A
1
160A
1
200A
1
250A
1
10A
1
16A
1
25A
1
35A
1
63A
1
63A
1
63A
1
80A
1
100A
1
125A
1
160A
1
250A
1
250A
®
MG.11.L4.02 - ADAP-KOOL Drive
Voltage Type
200-240 V type gG
200-240 V type gG
200-240 V type gG
200-240 V type gG
200-240 V type gG
200-240 V type gG
200-240 V type gG
200-240 V type gG
200-240 V type gG
200-240 V type gG
200-240 V type gG
200-240 V type gG
200-240 V type aR
200-240 V type aR
380-500 V type gG
380-500 V type gG
380-500 V type gG
380-500 V type gG
380-500 V type gG
380-500 V type gG
380-500 V type gG
380-500 V type gG
380-500 V type gG
380-500 V type gG
380-500 V type gG
380-500 V type aR
380-500 V type aR
®
Drive
