7.1.2 Quick Menu Mode
Parameter Data
The graphical display (GLCP) provides access to all parameters listed under the Quick Menus. To set parameters using the
[Quick Menu] button - enter or change parameter data or settings in accordance with the following procedure:
1. Press Quick Menu button
2.
Use the [
3. Press [OK]
4.
Use [
5. Press [OK]
6.
To move to a different digit within a parameter setting, use the [
7. Highlighted area indicates digit selected for change
8. Press [Cancel] button to disregard change, or press [OK] to accept change and enter the new setting
Example of Changing Parameter Data
7 7
Assume parameter 22-60, Broken Belt Function is set to [Off]. However, you want to monitor the fan-belt condition - non-
broken or broken - according to the folowing procedure:
1. Press Quick Menu key
2.
Choose Function Setups with the [
3. Press [OK]
4.
Choose Application Settings with the [
5. Press [OK]
6. Press [OK] again for Fan Functions
7. Choose Broken Belt Function by pressing [OK]
8.
With [
The frequency converter will now trip if a broken fan-belt is detected.
Select [My Personal Menu] to display only the parameters, which have been pre-selected and programmed as personal
parameters. For example, an AHU or pump OEM may have pre-programmed these to be in My Personal Menu during
factory commissioning to make on-site commissioning / fine tuning simpler. These parameters are selected in par. 0-25
Personal Menu. Up to 20 different parameters can be programmed in this menu.
If [No Operation] is selected in par. 5-12 Terminal 27 Digital Input, no connection to +24 V on terminal 27 is necessary to
enable start.
If [Coast Inverse] (factory default value) is selected in par. 5-12 Terminal 27 Digital Input, a connection to +24V is necessary
to enable start.
Select [Changes Made] to get information about:
•
the last 10 changes. Use the up/down navigation keys to scroll between the last 10 changed parameters.
•
the changes made since factory setting.
Select [Loggings] to get information about the display line read-outs. The information is shown as graphs.
Only display parameters selected in par. 0-20 and par. 0-24 can be viewed. It is possible to store up to 120 samples in the
memory for later reference.
