Electrical Installation
3. Press [OK] to activate the AMA par. 1-29.
4. Choose between complete or reduced AMA. If
sine wave filter is mounted, run only reduced
AMA, or remove sine wave filter during AMA
procedure.
5. Press [OK] key. Display should show "Press [Hand
on] to start".
6. Press [Hand on] key. A progress bar indicates if
AMA is in progress.
Stop the AMA during operation
5 5
1. Press the [OFF] key - the frequency converter
enters into alarm mode and the display shows
that the AMA was terminated by the user.
Successful AMA
1. The display shows "Press [OK] to finish AMA".
2. Press the [OK] key to exit the AMA state.
Unsuccessful AMA
1. The frequency converter enters into alarm mode.
A description of the alarm can be found in the
Troubleshooting section.
2. "Report Value" in the [Alarm Log] shows the last
measuring sequence carried out by the AMA,
before the frequency converter entered alarm
mode. This number along with the description of
the alarm will assist troubleshooting. If contacting
Danfoss Service, make sure to mention number
and alarm description.
NOTE
Unsuccessful AMA is often caused by incorrectly entered
motor name plate data or too big difference between the
motor power size and the frequency converter power size.
Step 4. Set speed limit and ramp time
Set up the desired limits for speed and ramp time.
Minimum Reference
Maximum Reference
Motor Speed Low Limit
Motor Speed High Limit
Ramp-up Time 1 [s]
Ramp-down Time 1 [s]
See the section How to programme the frequency converter,
Quick Menu Mode for an easy set-up of these parameters.
44
®
ADAP-KOOL Drive Operating Instructions
par. 3-02
par. 3-03
par. 4-11 or 4-12
par. 4-13 or 4-14
par. 3-41
par. 3-42
