How to Programme the Frequ...
The Function Setup parameters are grouped in the following way:
Q3-10 Adv. Motor Settings
1-90 Motor Thermal Protection
1-93 Thermistor Source
1-29 Automatic Motor Adaption
14-01 Switching Frequency
1-00 Configuration Mode
3-02 Minimum Reference
3-03 Maximum reference
3-15 Reference 1 Source
6-10 Terminal 53 Low Voltage
6-11 Terminal 53 High Voltage
6-14 Terminal 53 Low Reference / Feedb. value
6-15 Terminal 53 High ref / Feed. value
3-10 Preset reference
1-00 Configuration mode
20-00 Feedback 1 Source
20-12 Reference/Feedback Unit
6-20 Term 54 low voltage
6-21 Term 54 high voltage
6-22 Terminal 54 Low Current (only visible if switch set to I)
6-23 Terminal 54 High Current (only visible if switch set to I)
6-24 Terminal 54 Low ref / Feedb. value
6-25 Terminal 54 High ref / Feedb. value
3-02 Min. Reference
3-03 Max. Reference
20-21 Setpoint 1
20-93 PID Proportional Gain
20-94 PID Integral Time
3-13 Reference site
Compressor
22-75 Short Cycle Protection
22-76 Interval between Starts
22-77 Minimum Run Time
20-00 Feedback 1 Source
20-01 Feedback 1 Conversion
20-02 Feedback 1 Source Unit
20-30 Refrigerant
20-40 ThermostatPressostat
20-41 Cut-out value
20-42 Cut-in value
25-00 Pack Controller
25-06 Number of compressors
25-20 Neutral zone
25-21 +zone
25-22 -zone
®
See also ADAP-KOOL Drive AKD102 Programming Guide for a detailed description of the Function Setups parameter groups.
®
ADAP-KOOL Drive Operating Instructions
Q3-1 General Settings
Q3-11 Analog Output
6-50 Terminal 42 Output
6-51 Terminal 42 Output min. scale 0-71 Date format
6-52 Terminal 42 Output max. scale 0-72 Time format
Q3-2 Open Loop Settings
Q3-3 Closed Loop Settings
Q3-4 Application Settings
Condenser
22-40 Minimum run time
22-41 Minumum sleep time
22-42 Wake-up Speed [RPM]
22-43 Wake-up Speed [Hz]
22-44 Wake up ref. /FB difference
20-00 Feedback 1 Source
20-01 Feedback 1 Conversion
20-02 Feedback 1 Source Unit
20-30 Refrigerant
20-40 ThermostatPressostat
20-41 Cut-out value
20-42 Cut-in value
MG.11.L4.02 - ADAP-KOOL
Q3-12 Clock Settings
0-70 Set date and time
0-74 DST/Summertime
0-76 DST/Summertime start
0-77 DST/Summertime end
Single fan/ pump
22-40 Minimum run time
22-41 Minumum sleep time
22-42 Wake-up Speed [RPM]
22-43 Wake-up Speed [Hz]
22-44 Wake up ref. /FB difference
®
Drive
Q3-13 Display Settings
0-20 Display Line 1.1 Small
0-21 Display Line 1.2 Small
0-22 Display Line 1.3 Small
0-23 Display Line 2 large
0-24 Display Line 3 large
0-37 Display Text 1
0-38 Display Text 2
0-39 Display Text 3
