3-13 Reference Site
Option: Function:
Select which reference site to activate.
[0] Linked to Use local reference when in Hand mode; or
*
Hand / Auto remote reference when in Auto mode.
[1] Remote Use remote reference in both Hand mode
and Auto mode.
[2] Local Use local reference in both Hand mode and
Auto mode.
NOTE
When set to Local [2], the frequency
converter will start with this setting
again following a 'power down'.
3-15 Reference 1 Source
Option: Function:
Select the reference input to be used
for the first reference signal.
3-15 Reference 1 Source, 3-16 Reference
2 Source and 3-17 Reference 3 Source
define up to three different reference
signals. The sum of these reference
signals defines the actual reference.
This parameter cannot be adjusted
while the motor is running.
[0] No function
[1] Analog input 53
*
[2] Analog input 54
[7] Pulse input 29
[8] Pulse input 33
[20] Digital pot.meter
[21] Analog input X30/11
[22] Analog input X30/12
[23] Analog Input X42/1
[24] Analog Input X42/3
[25] Analog Input X42/5
[30] Ext. Closed Loop 1
[31] Ext. Closed Loop 2
[32] Ext. Closed Loop 3
6-10 Terminal 53 Low Voltage
Range: Function:
0.07 V [0.00 - par. Enter the low voltage value. This analog
*
6-11 V] input scaling value should correspond to
the low reference/feedback value set in
6-14 Terminal 53 Low Ref./Feedb. Value.
6-11 Terminal 53 High Voltage
Range: Function:
10.00 V [par. 6-10 - Enter the high voltage value. This
*
10.00 V] analog input scaling value should
correspond to the high reference/
®
ADAP-KOOL Drive Operating Instructions
6-11 Terminal 53 High Voltage
Range:
6-14 Terminal 53 Low Ref./Feedb. Value
Range:
0.000 N/A
6-15 Terminal 53 High Ref./Feedb. Value
Range:
100.000
N/A
*
6-20 Terminal 54 Low Voltage
Range:
0.07 V
*
6-21 Terminal 54 High Voltage
Range:
10.00 V
*
6-22 Terminal 54 Low Current
Range:
4.00
mA
*
6-23 Terminal 54 High Current
Range:
20.00 mA
®
MG.11.L4.02 - ADAP-KOOL Drive
Function:
feedback value set in 6-15 Terminal 53
High Ref./Feedb. Value.
Function:
[-999999.999 - Enter the analog input scaling
*
999999.999 N/A] value that corresponds to the
low voltage/low current set in
6-10 Terminal 53 Low Voltage
and 6-12 Terminal 53 Low
Current.
Function:
[-999999.999 - Enter the analog input scaling
999999.999 N/A] value that corresponds to the
high voltage/high current
value set in 6-11 Terminal 53
High Voltage and
6-13 Terminal 53 High Current.
Function:
[0.00 - par. Enter the low voltage value. This analog
6-21 V] input scaling value should correspond to
the low reference/feedback value, set in
6-24 Terminal 54 Low Ref./Feedb. Value.
Function:
[par. 6-20 - Enter the high voltage value. This
10.00 V] analog input scaling value should
correspond to the high reference/
feedback value set in 6-25 Terminal 54
High Ref./Feedb. Value.
Function:
[0.00 - Enter the low current value. This reference
par. 6-23 signal should correspond to the low
mA] reference/feedback value, set in
6-24 Terminal 54 Low Ref./Feedb. Value. The
value must be set at >2 mA in order to
activate the Live Zero Time-out Function in
6-01 Live Zero Timeout Function.
Function:
[par. 6-22 - Enter the high current value
*
20.00 mA] corresponding to the high reference/
feedback value set in 6-25 Terminal
54 High Ref./Feedb. Value.
