1-23 Motor Frequency
Range:
Function:
50.
[20 -
Select the motor frequency value from the
Hz
1000 Hz]
motor nameplate data.For 87 Hz operation
*
with 230/400 V motors, set the nameplate
data for 230 V/50 Hz. Adapt 4-13 Motor
Speed High Limit [RPM] and 3-03 Maximum
Reference to the 87 Hz application.
NOTE
This parameter cannot be adjusted while the motor is
running.
1-24 Motor Current
Range:
Function:
7.20 A
[0.10 - 10000.00
Enter the nominal motor current
*
A]
value from the motor nameplate data.
This data is used for calculating motor
torque, motor thermal protection etc.
NOTE
This parameter cannot be adjusted while the motor is
running.
1-25 Motor Nominal Speed
Range:
Function:
1420. RPM
[100 - 60000
Enter the nominal motor speed
*
RPM]
value from the motor nameplate
data. This data is used for
calculating automatic motor
compensations.
NOTE
This parameter cannot be adjusted while the motor is
running.
1-39 Motor Poles
Range:
Function:
4.
[2 -
Enter the number of motor poles.
N/A
100
*
Poles ~n
@ 50 Hz
n
N/A]
2
2700 - 2880
4
1350 - 1450
6
700 - 960
The table shows the number of poles for normal
speed ranges of various motor types. Define
motors designed for other frequencies separately.
The motor pole value is always an even number,
because it refers to the total number of poles, not
pairs of poles. The frequency converter creates the
initial setting of 1-39 Motor Poles based on
1-23 Motor Frequency Motor Frequency and
1-25 Motor Nominal Speed Motor Nominal Speed.
This parameter cannot be adjusted while the
motor is running.
®
ADAP-KOOL
Drive Operating Instructions
4-12 Motor Speed Low Limit [Hz]
Range:
Application
Dependent
4-14 Motor Speed High Limit [Hz]
Range:
50/60.0
Hz
*
NOTE
Max. output frequency cannot exceed 10% of the inverter
switching frequency (14-01 Switching Frequency).
3-02 Minimum Reference
Range:
0 ReferenceFeed-
backUnit
~n
@60 Hz
n
3250 - 3460
1625 - 1730
840 - 1153
®
MG.11.L4.02 - ADAP-KOOL
Function:
[0 - par.
Enter the minimum limit for motor
4-14 Hz]
speed. The Motor Speed Low Limit
*
can be set to correspond to the
minimum output frequency of the
motor shaft. The Speed Low Limit
must not exceed the setting in
4-14 Motor Speed High Limit [Hz].
Function:
[par.
Enter the maximum limit for motor speed.
4-12 -
The Motor Speed High Limit can be set to
par. 4-19
correspond to the manufacturer's
Hz]
recommended maximum of the motor
shaft. The Motor Speed High Limit must
exceed the in 4-12 Motor Speed Low Limit
[Hz]. Only 4-11 Motor Speed Low Limit
[RPM] or 4-12 Motor Speed Low Limit [Hz]
will be displayed depending on other
parameters in the Main Menu and
depending on default settings dependant
on global location.
[-999999.999 -
par. 3-03
*
ReferenceFeed-
backUnit]
Drive
7
Function:
Enter the Minimum
Reference. The Minimum
Reference is the lowest
value obtainable by
summing all references.
The Minimum Reference
value and unit matches
the configuration choice
made in 1-00 Configu-
ration Mode and
20-12 Reference/Feedback
Unit, respectively.
NOTE
This parameter is used
in open loop only.
59
7
