5.1.8 Tips and tricks

*
*
*
*
*
5 5
*
Table 5.1 Tips and Tricks
5.1.9 Quick Transfer of Parameter Settings
When Using Keypad
Once the set-up of an adjustable frequency drive is
complete, it is recommended to store (backup) the
parameter settings in the or on a PC via DCT 10 software.
WARNING
Stop the motor before performing any of these operations.
Data storage in LCP:
1. Go to 0-50 LCP Copy
2. Press the [OK] key
3. Select "All to LCP"
4. Press the [OK] key
All parameter settings are now stored in the keypad
indicated by the progress bar. When 100% is reached,
press [OK].
The keypad can now be connected to another adjustable
frequency drive and the parameter settings copied to this
adjustable frequency drive.
Data transfer from LCP to adjustable frequency drive:
1. Go to 0-50 LCP Copy
2. Press the [OK] key
3. Select "All from LCP"
4. Press the [OK] key
The parameter settings stored in the graphical keypad are
now transferred to the adjustable frequency drive
indicated by the progress bar. When 100% is reached,
press [OK].
5-6
VLT AQUA 12-Pulse High Power Instruction Manual
For the majority of water and wastewater applications, the Quick Menu, Quick Set-up and Function Set-ups provide the
simplest and quickest access to all of the typical parameters required.
Whenever possible, performing an AMA will ensure best shaft performance.
The contrast of the display can be adjusted by pressing [Status] and [▲] for a darker display or by pressing [Status]
and [▼] for a brighter display
Under [Quick Menu] and [Changes Made], all the parameters that have been changed from the factory settings are
displayed.
Press and hold the [Main Menu] key for 3 seconds to access any parameter.
For service purposes, it is recommended to copy all parameters to the LCP, see par 0-50 for further information.
MG.20.Y1.22 - VLT
5.1.10 Restore Factory Settings
There are two ways to restore the drive to factory settings:
Recommended restore and manual restore.
Please be aware that they have different impacts according
to the below description.
Recommended restore (via 14-22 Operation Mode)
1. Select 14-22 Operation Mode
2. Press [OK]
3. Select [2] Restore Factory Settings
4. Press [OK]
5. Disconnect the power from the unit and wait for
the display to turn off.
6. Reconnecting the power resets the adjustable
frequency drive. Note that first start-up takes a
few more seconds
7. Press [Reset]
14-22 Operation Mode restores all except:
14-50 RFI 1
8-30 Protocol
8-31 Address
8-32 Baud Rate
8-35 Minimum Response Delay
8-36 Max Response Delay
8-37 Max Inter-Char Delay
15-00 Operating Hours to 15-05 Over Volts
15-20 Historic Log: Event to 15-22 Historic Log: Time
15-30 Alarm Log: Error Code to 15-32 Alarm Log: Time
Manual restore
NOTE!
When carrying out manual restore, serial communication,
RFI filter settings and fault log settings are reset.
.
®
