Save frequency converter settings:
1. Connect a PC to the unit via USB com port.
(NOTE: Use a PC, which is isolated from the mains
with the USB port. Failure to do so may damage
the equipment.
2. Open MCT 10 Set-up Software.
3. Select Read from drive.
4. Select Save as.
All parameters are now stored in the PC.
Load frequency converter settings:
1. Connect a PC to the frequency converter via USB
com port.
2. Open MCT 10 Set-up Software.
3. Select Open – stored files are shown.
4. Open the appropriate file.
5. Select Write to drive.
All parameter settings are now transferred to the
frequency converter.
A separate manual for MCT 10 Set-up Software is available
at www.Danfoss.com/BusinessAreas/DrivesSolutions/Software-
download/DDPC+Software+Program.htm.
The MCT 10 Set-up Software modules
The following modules are included in the software
package.
MCT Set-up 10 Software
Setting parameters.
Copy to and from frequency converters.
Documentation and print of parameter settings,
including diagrams.
Ext. user interface
Preventive Maintenance Schedule.
Clock settings.
Timed Action Programming.
Smart Logic Controller Set-up.
Table 5.1 The MCT 10 Set-up Software Modules
Ordering number
Order the CD containing MCT 10 Set-up Software using
code number 130B1000.
The software can be downloaded from the Danfoss
internet site at www.Danfoss.com/BusinessAreas/DrivesSo-
lutions/Softwaredownload/DDPC+Software+Program.htm
MG11F502
Operating Instructions

5.3.3 Tips and Tricks

•
•
•
•
•
•
5.3.4 Quick Transfer of Parameter Settings
when Using GLCP
Once the set-up of a frequency converter is complete,
store (back up) the parameter settings in the GLCP or on a
PC via MCT 10 Set-up Software.
WARNING
Stop the motor before performing any of these
operations.
Data storage in the LCP:
1.
2.
3.
4.
All parameter settings are now stored in the GLCP
indicated by the progress bar. When 100% is reached,
press [OK].
The GLCP can now be connected to another frequency
converter and the parameter settings copied to this
frequency converter.
Data transfer from the LCP to the frequency converter
1.
2.
3.
4.
The parameter settings stored in the GLCP are now
transferred to the frequency converter indicated by the
progress bar. When 100% is reached, press [OK].
Danfoss A/S © 08/2014 All rights reserved.
For most HVAC applications, the Quick Menu,
Quick Set-up and Function Set-up provide the
simplest and quickest access to the most required
parameters.
Whenever possible, performing an AMA ensures
the best shaft performance.
Adjust display contrast by pressing [Status] and
▲
[ ] for darker display, or by pressing [Status] and
▼
[ ] for brighter display.
Under Quick Menu and Changes Made, all
parameters which have been changed from
factory settings are displayed.
Press and hold [Main Menu] key for 3 s to access
to any parameter.
For service purposes, copy all parameters to the
LCP. See 0-50 LCP Copy for further information.
Go to 0-50 LCP Copy.
Press [OK].
Select [1] All to LCP.
Press [OK].
Go to 0-50 LCP Copy.
Press [OK].
Select [2] All from LCP.
Press [OK].
