Clean the Printhead Cam Rollers

Use the double-sided, sticky cleaning card to clean the printhead cam rollers. Perform this
procedure first.
1.
Power off the printer, if necessary.
2.
Unlock the access door lock and open the printer access door.
3.
Remove the retransfer cartridge (C2) from the
printer.
4.
Peel off the wrapper from one side of the sticky cleaning card.
5.
Insert the cleaning card vertically into the printer between the retransfer cartridge guidepost
and the rollers. Make sure that the adhesive side of the card is facing to the right and is
touching the rollers.
Move the cleaning
card up and down
Ink Ribbon
Cartridge
Guidepost
6.
Move the cleaning card up and down along the rollers to remove any debris found on the
rollers.
7.
Continue with
CR825 and CE875 Instant Issuance System User's Guide
Sticky
Cleaning Card
Printhead
Cam Rollers
"Clean the Inside of the Printer"
Sticky Cleaning
Card
on page 46.
45
