The Front and Right Side of the Printer

Use the following sections to become familiar with the printer.

Single-Hopper Printer

Input
Hopper
Output
Hopper
Input Hopper
Output Hopper
Front Panel
Input Hopper Lock
4
Input Hopper
Front
Lock
Panel
The input hopper holds cards for printing. The hopper holds
up to 125 cards (0.030 in. or 0.762 mm thickness).
Note: the input hopper can be removed from the printer for
secure storage.
The output hopper holds up to 25 completed cards.
The front panel allows you to work with the printer. It includes
the P button, the U
OWER
panel with navigation keys. Refer to
page 19 for a description of the front panel items.
The input hopper lock secures the input hopper. The lock can
be opened using a key or a command from your card
personalization software.
Sending a command to open the lock opens all locks on the
printer and on any attached component.
Printer Access
Door
Access Door
Lock
Access Door
Handle
button, status lights, and the LCD
SER
"Use the Front Panel" on
About the Printer
