Load Embosser Supplies

Embossing supplies include topping foil and indent ribbon. The topping foil is applied to the
embossed characters and can be applied to up to five lines of characters. The indent ribbon is
used to apply black or white color to a single line of indented characters.
If the embosser supplies are preloaded into their cartridges, install the cartridges into the
embosser.
The topping foil and indent ribbon cartridges are not interchangeable. They fit only
into the designated cartridge area.

Load the Indent Ribbon Cartridge

1.
Prepare the indent ribbon cartridge and indent roll.
a.
Unlock and open the embosser supplies
access door and remove the indent ribbon
cartridge from the embosser. The indent
ribbon cartridge is on the right as you face
the embosser opening.
b.
Place the indent ribbon cartridge on a flat
surface with the spindles facing up.
c.
Remove the used indent ribbon spools from
the cartridge and discard them according to
your site's security procedures.
d.
Remove the new indent roll from its package.
IMPORTANT! Do not separate the silver take-
up spool away from the blue supply spool.
2.
Secure the blue supply spool into the spindle.
a.
Match the keyed pattern of the supply spool
hub with the left side spindle.
b.
Push the supply spool into the spindle until it
clicks securely into place.
A-6
Supply
Spool
CE875 Instant Issuance System
Take-up
Spool
