Serial LEDs

Table 3-6
Table 3-6.
LED
RLSD3
(Received Line
Signal Detection 3)
RLSD4
(Received Line
Signal Detection 4)
RLSD5
(Received Line
Signal Detection 5)

Adapter Module LEDs

An ARN adapter module can contain serial, ISDN, DSU/CSU, or V.34 modem
LEDs.

Serial LED

Table 3-7
Table 3-7.
LED
RLSD
(Received Line
Signal Detection)
3-6
describes the expansion module serial interface LEDs.
Expansion Module Serial LEDs
Meaning
Lights when Received Line Signal Detection is active on
COM 3.
Lights when Received Line Signal Detection is active on
COM 4.
Lights when Received Line Signal Detection is active on
COM 5.
describes the serial adapter module LED.
Serial LED
Meaning
Lights when Received Line Signal Detection is active on the
serial interface.
