Removing a Flash Memory Card

To remove a memory card from an ARN:
1.
2.
Caution: Do not remove the Flash memory card while the router is operating.
Removing the memory card interferes with current networking operations.
100-240~
1.2A
50-60Hz
Figure 3-4. Removing an ARN Flash Memory Card
To insert another memory card into the receptacle, refer to "Installing the Flash
Memory Card" in Chapter 2.
When you remove a formatted memory card, the NVFS automatically removes
access to the card. When you insert and format a card or insert an already
formatted card, the NVFS automatically provides access.
3-12
Press the Eject button next to the card receptacle on the back panel.
Pull the memory card out of the card receptacle.
See Figure 3-4.
U L
Redundant Power
U L
Console
1
2
114200 Rev. A
Modem
ARN0053A
