Installing and Operating BayStack ARN Routers

Connecting a Modem

You can connect a modem to the ARN using the back-panel modem port or you
can connect a telephone line directly to an optional, back-panel V.34 modem
adapter module.
Note: To use the Netboot, Directed Netboot, or Local Boot software
configuration options, you must connect a console the first time you power up
the ARN. Refer to Chapter 3 for details.
A modem provides remote access to the ARN for a system administrator. We
recommend that you connect a modem in case the ARN experiences system
problems.

Connecting to the Back-Panel Modem Port

To connect a modem to the ARN back panel, you need an AT (or Hayes)
compatible modem and the Order No. 110307 modem cable that came in the ARN
console/modem cable kit.
Note: Do not use the Order No. 110308 null modem crossover adapter in the
ARN cable kit to connect to a modem.
Complete the following steps:
1.
Table 1-4.
Modem Signal/Parameter
Clear To Send (CTS)
Data Terminal Ready (DTR)
Data Carrier Detect (DCD) or RLSD On while carrier is present (the ARN uses DCD to
Data Set Ready (DSR)
Ready to Send (RTS)
1-24
Configure the modem, using the parameters in
External Modem Parameters
Table
Value
On
Set to answer all incoming calls.
detect modem connect and disconnect).
On
Ignored
1-4.
(continued)
114200 Rev. A
