Installing and Operating BayStack ARN Routers
If you are installing your ARN in an electronic enclosure rack, make sure that the
rack meets the following specifications:
•
•
•
•
Electrical Specifications
Your installation site must meet the following power requirements:
•
•
•
Table C-1
Table C-1.
Country
United States/
Canada
Any other country Your ARN distributor informs you of the
Environmental Specifications
The environmental requirements of the ARN are as follows:
•
•
•
C-2
Heavy-duty steel construction
Electronic Industries Association (EIA) standard hole-spacing
Width of 19 in. (48.26 cm)
Depth of 24 in. (60.96 cm)
Proximity to wall receptacle: within 6 ft (1.8 m) of the ARN
Voltage: 100 to 240 Vac
Amperage: 0.5 to 1.0 A
lists the wall outlet requirements.
ARN Wall Outlet Requirements
Outlet
National Electrical Manufacturers
Association (NEMA) 5-15P standard outlet
outlet you need.
Altitude: 0 to 8,000 ft (0 to 2,438.4 m)
Humidity: 10% to 90%, noncondensing
Temperature: 32 F to 104 F (0 C to 40 C) stable
Voltage
100 to 120 V
200 to 240 V
114200 Rev. A
