Alternative
bracket
position
(2 places)
Figure 1-2. Attaching Flange Brackets to Rack-Mount the ARN
2.
114200 Rev. A
Align the holes in the shorter end of the flange bracket with the holes in
the front vertical supports of the rack
Installing the BayStack Advanced Remote Node
Screws
(8 places)
(Figure 1-3).
ARN0004A
1-7
