Installing and Operating BayStack ARN Routers
Bay Networks Proprietary PPP Worksheet
Requested Information
Enter Remote Address
selection [3]:
Frame Relay Worksheet
Requested Information
Enter Management type [3]:
Enter addressing type [4]:
Enter address field length [2]:
Enter DLCI number [30]:
(For DLCMI None, LMI Switch, Annex
D Switch, and Annex A Switch only)
B-12
(continued)
Options
1. DCE
2. DTE
3. EXPLICIT
Note: Reverse local and remote
address values when
configuring the device at the
other end of the circuit.
(Exception: When connecting to
a Series 5 router that uses
DCE/DTE addressing, use the
SAME local address value.)
Options
1. DLCMI None
2. Rev 1 LMI
3. ANSI T1 617D
4. CCITT Annex A
5. LMI Switch
6. Annex D Switch
7. Annex A Switch
1. ADDR Q.921
2. ADDR Q.922 (MARCH '90)
3. ADDR Q.922 (NOVEMBER
'90)
4. ADDR Q.922
2. Two Bytes
3. Three Bytes
4. Four Bytes
Enter the permanent virtual
channel (PVC) number.
Note: The valid range for the DLCI
number is between 16 and 1007.
Your Response
Your Response
114200 Rev. A
