Installing and Operating BayStack ARN Routers

Ethernet LEDs

Table 3-2
Table 3-2.
LED
Tx
(Transmit)
Rx
(Receive)
Cl
(Collision)

Token Ring LEDs

Table 3-3
Table 3-3.
LED
RCVR
(Receiver)
NSRT
(Insert)
WFLT
(Wire Fault)
3-4
describes the base module Ethernet LEDs.
Base Module Ethernet LEDs
Meaning
Lights when the Ethernet interface transmits data.
Lights when the Ethernet interface receives data.
Lights when the Ethernet interface detects a collision.
describes the base module token ring LEDs.
Base Module Token Ring LEDs
Meaning
Lights when the interface is connected to the network.
Lights when you insert the ARN into the token ring network.
Lights when the token ring hardware detects a wire fault
condition.
114200 Rev. A
