Installing and Operating BayStack ARN Routers
To connect to a V.34 modem interface:
1.
Front-panel V.34 Modem Interface
1
RLSD
Telco
Tx
2
V.34 Modem
Rx
To
RJ-11 telephone
receptacle
Figure 1-13. Connecting an RJ-11Cable
2.

Connecting a Management Console

Use t
computer terminal emulator to the ARN.
Using a local terminal, you can monitor the results of startup diagnostics and set
the boot configuration. Using an attached modem, you can allow remote dial-in
access to diagnostics.
Note: To use the Netboot, Directed Netboot, or Local Boot software
configuration options, you must connect a console the first time you power up
the ARN, as described in Chapter 3.
1-20
Insert the RJ-11 telephone cable into the V.34 modem interface labeled
Telco (Figure 1-13).
COM
Serial
RLSD
DTR
ARN0071A
Connect the other end of the cable to an analog telephone line (for
example, the telephone wall receptacle).
he back-panel console port to connect an ASCII-based terminal or a personal
Back-panel V.34 Modem Interface
1
Tx
Rx
Cl
1
Tx
Rx
Cl
To
RJ-11 telephone
receptacle
Tx RLSD
Modem
DTR
Rx
Console Modem
ARN0072A
114200 Rev. A
