Installing and Operating BayStack ARN Routers

ARN Token Ring Base Model Safety Status

Table D-2
other equipment.
Table D-2.
Port Location
MAU
Console

ARN Expansion Modules Safety Status

Order Numbers CV0004011, CV0004012, CV0004013, CV0004014,
CV0004015 are upgrade options that provide an additional synchronous interface.
These options can be installed in any ARN model.
Table D-3
COM5) provided by Order Nos. CV0004011, CV0004012, CV0004013,
CV0004014, CV0004015 to the connection of other equipment.
Table D-3.
Port Location
COM3, COM4, and COM5
AUI
10Base-T
MAU
J2
D-2
lists the safety status of interconnection points to the connection of
Safety Status (Order Nos. CV1101001, CV1101002,
CV1101003, CV1101004, CV1101005)
Port Description
Token Ring
V.28
lists the safety status of the interconnection point (COM3, COM4,
Safety Status (Order Nos. CV0004011, CV0004012,
CV0004013, CV0004014, CV0004015)
Port Description
V.28, X.21, V.35
Ethernet AUI
Ethernet 10Base-T
Token Ring
Host Port
Type of Circuit
SELV
SELV
Type of Circuit
Telecommunications
network voltage (TNV) at
SELV levels
SELV
SELV
SELV
SELV
114200 Rev. A
