Installing and Operating BayStack ARN Routers

ISDN BRI Adapter Module Requirements

The ISDN BRI Adapter module (Order No. CV0004002) is approved only for
installation in a host, and with host attachments, which are either type approved
for such apparatus or, if supplied after 1st March 1989, are marked with or
supplied with a statement that the host is supplied under the terms of General
Approval Number NS/G/1234/J/100003.
Installation of the ISDN BRI module in any BayStack ARN chassis (Order Nos.
CV1001001, CV1001002, CV1001003, CV1001004, CV1001005, CV1101001,
CV1101002, CV1101003, CV1101004, CV1101005) complies with all
requirements listed in this section. Installation of the ISDN BRI upgrade module
in any ARN complies with all requirements listed in this section.
Table D-8
other equipment.
Table D-8.
Port Location
ISDN
P6
Table D-9
Table D-9.
Pin
1
2
3
4
5
6
7
8
D-8
lists the safety status of interconnection points to the connection of
ISDN BRI Safety Status (Order No. CV0004002)
Port Description
BRI ISDN
Host Port
lists the ISDN connector pinouts.
ISDN Connector Pinouts
Signal
No connection
No connection
Tx+
Rx+
Tx-
Rx-
No connection
No connection
Type of Circuit
TNV at SELV levels
SELV
114200 Rev. A
