Verifying Site Requirements

The installation site must provide a certain amount of free space around the ARN
to dissipate heat, as detailed in
Table 1-1.
Width
22.5 in. (57.2 cm)
In addition, the installation site must meet the electrical and environmental
specifications listed in Appendix C.
Caution: You must use grounded electrical power outlets with the ARN.

Installing the ARN

Once you are ready to install the ARN in its final location, you can
•
•

Positioning the ARN on a Flat Surface

When positioning the ARN on a flat surface, make sure that the surface is
•
•
We recommend that you place the self-adhesive, rubber feet on the bottom of the
ARN chassis (shipped with the ARN). These feet not only protect the surface on
which you position the ARN, they provide added friction against the weight of
any cables that you attach to the device.
114200 Rev. A
Installation Space Requirements
Position the ARN on a flat, sturdy, horizontal surface.
Mount the ARN in an electronic enclosure rack.
Large enough for the ARN to operate properly
Sturdy enough to support the combined weight of the ARN and any cables
that you connect
Installing the BayStack Advanced Remote Node
Table 1-1.
Depth (minimum)
15 in. (38.1 cm)
Depth (for servicing)
25 in. (63.5 cm)
1-5
