Rack-Mounting the ARN

For this procedure, you need
•
•
•
•
Note: If the rack does not have threaded rail holes, you must supply and attach
four cagenuts.
To rack-mount the ARN:
1.
1-6
Four #10 cagenut screws and washers (shipped with the ARN)
Two flange brackets and eight #6 flathead screws (shipped with the ARN)
A Phillips screwdriver
An electronic enclosure rack
Attach a flange bracket to both sides of the ARN.
On each side of the chassis:
Align the holes in the longer end of the flange bracket with the
a.
mounting holes near the front panel of the ARN
Insert a #6 flathead screw through each hole and into the ARN.
b.
Tighten the four screws with a Phillips screwdriver.
c.
(Figure 1-2).
