Expansion Module LEDs

An ARN expansion module can contain Ethernet, token ring, or serial interface
LEDs.

Ethernet LEDs

Table 3-4
Table 3-4.
LED
Tx
(Transmit)
Rx
(Receive)
Cl
(Collision)

Token Ring LEDs

Table 3-5
Table 3-5.
LED
RCVR
(Receiver)
NSRT
(Insert)
WFLT
(Wire Fault)
114200 Rev. A
describes the expansion module Ethernet LEDs.
Expansion Module Ethernet LEDs
Meaning
Lights when the interface is transmitting data over the
network.
Lights when the interface is receiving data from the network.
Lights when the interface detects a collision on the network.
describes the expansion module token ring LEDs.
Expansion Module Token Ring LEDs
Meaning
Lights when the interface is connected to the network.
Lights when you insert the ARN into the Token Ring network.
Lights when the Token Ring hardware detects a wire fault
condition.
Operating the ARN
3-5
