Part No. 113629 Rev. A

Technical Notice

This document describes how to use Bay Networks™ Site Manager to conﬁgure a Model

5380 Ethernet Router or a Model 5580 Token Ring Router in a System 5000™ Hub.

Note: You can conﬁgure a Model 5380 Ethernet Router or a Model 5580

Token Ring Router in a System 5000 Hub using the UNIX version of Site

Manager only. The UNIX version of Site Manager runs on the Sun

SPARCstation, HP 9000, and IBM RS/6000.

This information supplements the instructions in the documentation set for Site Manager.

Bay Networks, Inc., Corporate Headquarters

4401 Great America Parkway, Santa Clara, CA 95054

8 Federal Street, Billerica, MA 01821

Table of Contents

Need help?

Do you have a question about the 5380 and is the answer not in the manual?

Page 1 This document describes how to use Bay Networks™ Site Manager to conﬁgure a Model 5380 Ethernet Router or a Model 5580 Token Ring Router in a System 5000™ Hub. Note: You can conﬁgure a Model 5380 Ethernet Router or a Model 5580 Token Ring Router in a System 5000 Hub using the UNIX version of Site Manager only.
Page 2 Conﬁguring a Model 5380 Ethernet Router or a Model 5580 Token Ring Router on a System 5000 Hub To conﬁgure a Model 5380 or 5580 Router on a System 5000 Hub: In the main Site Manager window, select Tools Conﬁguration Manager, and then choose an operating mode: Local File, Remote File, or Dynamic.
Page 3 Part No. 113629 Rev. A Figure 2. Conﬁguration Manager Window...
Page 4 Site Manager will not recognize the routers as a stack. In that case, each router functions as a separate router. Click on Module 3 in the slot in which you want to conﬁgure the Model 5380 or 5580 Router.
Page 5 In the same slot that you just speciﬁed for the router, select the module position of the net module (if any) on the router. Note: You can conﬁgure the net modules on a Model 5380 or 5580 Router in Module 1 or 2 only. If you attempt to conﬁgure the net modules in Module 3, Site Manager displays an error.
Page 6 For information about Access Stack Nodes, refer to Installing and Maintaining ASN Routers and BNX Platforms . For information on Model 5380 and 5580 Routers, refer to Using the Model 5380 Ethernet and the Model 5580 Token Ring Routers .
