Installing and Operating
BayStack ARN Routers
Router Software Version 11.00 Rev. 4n
Site Manager Software Version 5.00 Rev. 4n
Part No. 114200 Rev. A
November 1996

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BayStack ARN Routers none and is the answer not in the manual?

Questions and answers

Related Manuals for Bay Networks BayStack ARN Routers none

Summary of Contents for Bay Networks BayStack ARN Routers none

  • Page 1 Installing and Operating BayStack ARN Routers Router Software Version 11.00 Rev. 4n Site Manager Software Version 5.00 Rev. 4n Part No. 114200 Rev. A November 1996...
  • Page 2 4401 Great America Parkway Santa Clara, CA 95054 Copyright © 1988–1996 Bay Networks, Inc. All rights reserved. Printed in the USA. November 1996. The information in this document is subject to change without notice. The statements, configurations, technical data, and recommendations in this document are believed to be accurate and reliable, but are presented without express or implied warranty.
  • Page 3 USA Requirements Only Federal Communications Commission (FCC) Compliance Notice: Radio Frequency Notice This equipment generates, uses, and can radiate radio-frequency energy. If you do not install and use this equipment according to the instruction manual, this product may interfere with radio communications. This product has been tested and found to comply with the limits for a Class A computing device, pursuant to Subpart J of Part 15 of FCC Rules.

  • Page 4: Japan/Nippon Requirements Only

    Japan/Nippon Requirements Only Voluntary Control Council for Interference (VCCI) Statement Voluntary Control Council for Interference (VCCI) Statement This equipment is in the 1st category (information equipment to be used in commercial and/or industrial areas) and conforms to the standards set by the Voluntary Control Council for Interference by Data Processing Equipment and Electronic Office Machines that are aimed at preventing radio interference in commercial and/or industrial areas.
  • Page 5 Canada Requirements Only Canada CS-03 Rules and Regulations Note: The Canadian Department of Communications label identifies certified equipment. The certification means that the equipment meets certain telecommunications network protective operations and safety requirements. The Department does not guarantee the equipment will operate to the user's satisfaction. Before installing this equipment, users should ensure that it is permissible to be connected to the facilities of the local telecommunications company.
  • Page 6 Canada Requirements Only D. O. C. Explanatory Notes: Equipment Attachment Limitations The Canadian Department of Communications label identifies certified equipment. This certification meets certain telecommunication network protective, operational and safety requirements. The department does not guarantee the equipment will operate to the users satisfaction. Before installing the equipment, users should ensure that it is permissible to be connected to the facilities of the local telecommunications company.
  • Page 7 Canada Requirements Only Canadian Department of Communications Radio Interference Regulations This digital apparatus (Access Feeder Node, Access Link Node, Access Node, Access Stack Node, Backbone Concentrator Node, Backbone Concentrator Node Switch, Backbone Link Node, Backbone Link Node Switch, Concentrator Node, Feeder Node, Link Node) does not exceed the Class A limits for radio-noise emissions from digital apparatus as set out in the Radio Interference Regulations of the Canadian Department of Communications.
  • Page 8 Bay Networks Software License Note: This is Bay Networks basic license document. In the absence of a software license agreement specifying varying terms, this license -- or the license included with the particular product -- shall govern licensee’s use of Bay Networks software.
  • Page 9 Bay Networks Software License Licensee shall not reverse assemble, reverse compile, or in any way reverse engineer the Software. [Note: For licensees in the European Community, the Software Directive dated 14 May 1991 (as may be amended from time to time) shall apply for interoperability purposes. Licensee must notify Bay Networks in writing of any such intended examination of the Software and Bay Networks may provide review and assistance.] 10.

  • Page 11: Table Of Contents

    About This Guide Before You Begin ...xxi Conventions ...xxi Acronyms ...xxii Ordering Bay Networks Publications ...xxiv Technical Support and Online Services Bay Networks Customer Service ...xxvi Bay Networks Information Services ... xxvii World Wide Web ... xxvii Customer Service FTP ... xxvii Support Source CD ...
  • Page 12 Connecting to an Ethernet Interface ...1-10 Connecting to an AUI Interface ...1-11 Connecting to a 10Base-T Interface ...1-12 Connecting to a Token Ring Interface ...1-13 Connecting to an STP Token Ring Interface ...1-13 Connecting to a UTP Token Ring Interface ...1-14 Connecting to a Serial Interface ...1-15 Connecting to an ISDN Interface ...1-17 Connecting to a DSU/CSU Interface ...1-18...
  • Page 13 Chapter 3 Operating the ARN LED Descriptions ...3-2 Base Module LEDs ...3-2 Diagnostic LEDs ...3-2 Ethernet LEDs ...3-4 Token Ring LEDs ...3-4 Expansion Module LEDs ...3-5 Ethernet LEDs ...3-5 Token Ring LEDs ...3-5 Serial LEDs ...3-6 Adapter Module LEDs ...3-6 Serial LED ...3-6 ISDN BRI LEDs (S/T or U Interfaces) ...3-7 DSU/CSU LEDs ...3-7...
  • Page 14 Appendix B Using Local Boot (the Quick-Start Procedure) Understanding Quick-Start Connector Names and Numbers ... B-2 Filling Out the Worksheets ... B-3 Global Information Worksheet ... B-4 Router Protocol Worksheets ... B-7 Wide Area Protocol Worksheets ... B-11 Running the Quick-Start Script ... B-15 Appendix C Technical Specifications Physical Specifications ...
  • Page 15 Power Requirements for ISDN BRI and Serial Adapter Modules ... D-9 Clearance and Creepage Distances for ISDN BRI and Serial Adapter Modules ... D-9 Index 114200 Rev. A...
  • Page 17 Figure 1-1. Accessories in the ARN Shipping Container ...1-3 Figure 1-2. Attaching Flange Brackets to Rack-Mount the ARN ...1-7 Figure 1-3. Installing the ARN in an Electronic Enclosure Rack ...1-8 Figure 1-4. ARN Module Locations ...1-9 Figure 1-5. Connecting an AUI Cable ...1-11 Figure 1-6.
  • Page 18 Figure D-1. Cable 7837 (V.28 Compliant) ... D-3 Figure D-2. Cable 7220 (V.35 Compliant) ... D-4 Figure D-3. Cable 7224 (X.21 Compliant) ... D-6 Figure D-4. Clearance and Creepage Distances for ISDN BRI and Serial Adapter Modules ... D-10 xviii 114200 Rev.
  • Page 19 Table 1-1. Installation Space Requirements ...1-5 Table 1-2. V.34 Modem Adapter Module Defaults ...1-19 Table 1-3. Console Parameters ...1-21 Table 1-4. External Modem Parameters ...1-24 Table 1-5. Back-Panel V.34 Modem Defaults ...1-26 Table 2-1. Summary of Initial Startup Options ...2-2 Table 2-2.
  • Page 20 Table C-3. AUI Pin Assignments ... C-5 Table C-4. 10Base-T Interface Pin Assignments ... C-6 Table C-5. Token Ring STP Interface Pin Assignments ... C-7 Table C-6. Token Ring UTP Interface Pin Assignments ... C-8 Table C-7. Serial Interface Pin Assignments ... C-9 Table C-8.

  • Page 21: About This Guide

    This guide explains how to install, start, and operate a BayStack™ Advanced Remote Node™ (ARN™) router, including instructions to • Physically install the ARN • Attach communications equipment • Connect the ARN to the network using one of the software configuration options •...

  • Page 22: Acronyms

    italic text quotation marks (“ ”) separator ( > ) screen text vertical line ( Acronyms ANSI BootP CCITT CSMA/CD DLCMI xxii Indicates variable values in command syntax descriptions, new terms, file and directory names, and book titles. Indicate the title of a chapter or section within a book. Separates menu and option names in instructions and internal pin-to-pin wire connections.
  • Page 23 HDLC IEEE ISDN ITU-T NBMA NEMA NVFS OSPF PCMCIA RLSD SMDS SNMP TCP/IP TELNET TFTP 114200 Rev. A data terminal equipment data terminal ready Electronic Industries Association graphical user interface high-level data link control Institute of Electrical and Electronic Engineers Internet Protocol Integrated Services Digital Network International Organization for Standardization...

  • Page 24: Ordering Bay Networks Publications

    Ordering Bay Networks Publications To purchase additional copies of this document or other Bay Networks publications, order by part number from the Bay Networks Press telephone or fax numbers: • Telephone - U.S./Canada • Telephone - International • Fax You can also use these numbers to request a free catalog of Bay Networks Press product publications.

  • Page 25: Technical Support And Online Services

    Technical Support and Online Services To ensure comprehensive network support to our customers and partners worldwide, Bay Networks Customer Service has Technical Response Centers in key locations around the globe: • Billerica, Massachusetts • Santa Clara, California • Sydney, Australia •...

  • Page 26: Bay Networks Customer Service

    Bay Networks Customer Service If you purchased your Bay Networks product from a distributor or authorized reseller, contact that distributor’s or reseller’s technical support staff for assistance with installation, configuration, troubleshooting, or integration issues. Customers can also purchase direct support from Bay Networks through a variety of service programs.

  • Page 27: Bay Networks Information Services

    Bay Networks Information Services Bay Networks Information Services provide up-to-date support information as a first-line resource for network administration, expansion, and maintenance. This information is available from a variety of sources. World Wide Web The Bay Networks Customer Support Web Server offers a diverse library of technical documents, software agents, and other important technical information to Bay Networks customers and partners.

  • Page 28: Support Source Cd

    Support Source CD This CD-ROM -- sent quarterly to all contracted customers -- is a complete Bay Networks Service troubleshooting knowledge database with an intelligent text search engine. The Support Source CD contains extracts from our problem-tracking database; information from the Bay Networks Forum on CompuServe; comprehensive technical documentation, such as Customer Support Bulletins, Release Notes, software patches and fixes;...

  • Page 29: Infofacts

    InfoFACTS InfoFACTS is the Bay Networks free 24-hour fax-on-demand service. This automated system has libraries of technical and product documents designed to help you manage and troubleshoot your Bay Networks products. The system responds to a fax from the caller or to a third party within minutes of being accessed.

  • Page 31: Installing The Baystack Advanced Remote Node

    Installing the BayStack Advanced Remote Node This chapter describes how to install the BayStack ARN. Topics include the following: • Preparing to install the ARN • Installing the ARN • Connecting communication cables • Connecting a management console • Connecting a modem •...

  • Page 32: Preparing To Install The Arn

    Preparing to Install the ARN Verify the following before beginning the installation, as explained in the sections that follow: • Your shipment is complete and undamaged. • You have the proper equipment and tools. • Your installation site meets physical, electrical, and environmental requirements.
  • Page 33 Figure 1-1 illustrates the ARN shipping accessories. Power cable Console/modem cable (DB-9 receptacle to DB-25 plug cable) Figure 1-1. Accessories in the ARN Shipping Container 114200 Rev. A DB-25 receptacle null modem adapter Two flange brackets Eight #6 flathead screws Four cagenuts Four #10 cagenut screws and washers Four rubber feet...

  • Page 34: Supplying Equipment

    Supplying Equipment You may need items that are not part of the ARN accessory package. Before installing the ARN hardware, ensure that you have all the cables, tools, and other equipment that you need. Cables Unless they were specifically ordered, the cables necessary for your network configuration are not part of the ARN accessory package.

  • Page 35: Verifying Site Requirements

    Verifying Site Requirements The installation site must provide a certain amount of free space around the ARN to dissipate heat, as detailed in Table 1-1. Width 22.5 in. (57.2 cm) In addition, the installation site must meet the electrical and environmental specifications listed in Appendix C.

  • Page 36: Rack-Mounting The Arn

    Rack-Mounting the ARN For this procedure, you need • Four #10 cagenut screws and washers (shipped with the ARN) • Two flange brackets and eight #6 flathead screws (shipped with the ARN) • A Phillips screwdriver • An electronic enclosure rack Note: If the rack does not have threaded rail holes, you must supply and attach four cagenuts.
  • Page 37 Alternative bracket position (2 places) Figure 1-2. Attaching Flange Brackets to Rack-Mount the ARN Align the holes in the shorter end of the flange bracket with the holes in the front vertical supports of the rack 114200 Rev. A Screws (8 places) (Figure 1-3).
  • Page 38 Figure 1-3. Insert a cagenut screw through each bracket hole and into the corresponding holes in the rack. Tighten each cagenut screw with a Phillips screwdriver. 10BaseT ISDN BRI RLSD3 COM3 withNT1 RLSD4 RLSD5 Ethernet 2 RLSD 10BaseT Serial Base Expansion Boot Adapter1...

  • Page 39: Understanding The Arn Module Locations

    Understanding the ARN Module Locations The ARN is designed to scale to your needs. In addition to either an Ethernet or token ring base module, the ARN can contain an optional expansion module and up to two adapter modules ISDN BRI withNT1 RLSD Serial...

  • Page 40: Connecting Communications Cables

    The ARN also supports up to two of the following adapter modules: • Single serial interface • Single ISDN BRI S/T interface • Single ISDN BRI U interface • Single V.34 modem adapter interface • Single 56/64K DSU/CSU interface Connecting Communications Cables Gather the communications equipment and cabling that you will attach to the ARN.

  • Page 41: Connecting To An Aui Interface

    Connecting to an AUI Interface To connect an Ethernet AUI transceiver cable to an AUI interface: Caution: Connecting the ARN AUI interface directly to the AUI interface on an Ethernet station violates IEEE 802.3 standards. The AUI interface is designed only for connection to a transceiver. Connect an Ethernet AUI drop cable to the interface labeled AUI (Figure The cable must have a 15-position D-SUB receptacle.

  • Page 42: Connecting To A 10Base-T Interface

    Connecting to a 10Base-T Interface To connect an unshielded twisted-pair (UTP) cable to the base module or expansion module 10Base-T interface, insert the UTP jack into the RJ-45 interface, as shown in ISDN BRI withNT1 RLSD Serial Ethernet network Figure 1-6. Connecting a 10Base-T Ethernet Cable 1-12 Figure...

  • Page 43: Connecting To A Token Ring Interface

    Connecting to a Token Ring Interface You can connect a token ring cable to any ARN base module or expansion module that contains a token ring interface option. Each of these interface options offers two token ring interface types -- an STP interface or a UTP interface. Note: You can use only one token ring interface on an ARN base or expansion module at any time.

  • Page 44: Connecting To A Utp Token Ring Interface

    Connecting to a UTP Token Ring Interface To connect a Token Ring UTP cable to the expansion module token ring interface, insert the RJ-45 connector into the UTP interface, as shown in ISDN BRI withNT1 RLSD Serial Token Ring 1 Figure 1-8.

  • Page 45: Connecting To A Serial Interface

    Connecting to a Serial Interface The ARN supports up to five serial interfaces. You can connect • Up to three, 44-pin serial cables to an ARN that contains an Ethernet/tri-serial, Token Ring/tri-serial, or Tri-Serial expansion module • One, 44-pin serial cable to each Serial adapter module (the ARN can support two) To connect to a serial interface: Locate the RS-232, RS-422, RS-530, V.28, V.35, or X.21 interface cable.
  • Page 46 On an ARN adapter module, the serial interface is labeled COM (Figure RLSD Figure 1-10. Secure the cable to the interface using the capture screws on the cable. Connect the remote end of each cable to the appropriate communications equipment. 1-16 1-10).

  • Page 47: Connecting To An Isdn Interface

    Connecting to an ISDN Interface You can connect an ISDN cable to any ARN that contains an ISDN BRI S/T or U adapter module. To connect to an ISDN BRI interface: Insert the ISDN cable into the ISDN BRI interface RLSD ISDN switch...

  • Page 48: Connecting To A Dsu/Csu Interface

    Connecting to a DSU/CSU Interface You can connect a DSU/CSU cable to any ARN that contains a DSU/CSU adapter module. To connect to a DSU/CSU interface: Insert the DSU/CSU cable connector into the DSU/CSU interface labeled (Figure RLSD digital line wall jack Figure 1-12.

  • Page 49: Connecting To A V.34 Modem Interface

    Connecting to a V.34 Modem Interface You can connect an RJ-11 telephone cable to any ARN that contains a V.34 modem adapter module. Note: The default settings for the front-panel V.34 modem adapter module differ from the default settings for the back-panel V.34 modem. Refer to “Connecting to a V.34 Modem Module”...

  • Page 50: Connecting A Management Console

    To connect to a V.34 modem interface: Insert the RJ-11 telephone cable into the V.34 modem interface labeled Telco (Figure Front-panel V.34 Modem Interface RLSD Serial Telco RLSD V.34 Modem RJ-11 telephone receptacle Figure 1-13. Connecting an RJ-11Cable Connect the other end of the cable to an analog telephone line (for example, the telephone wall receptacle).

  • Page 51: Connecting A Terminal Console

    Connecting a Terminal Console You need both pieces in the ARN console/modem cable kit (Order No. 110310) to connect a terminal console: • Order No. 110307 serial console/modem cable (with 9-pin receptacle to 25-pin plug connectors) • Order No. 110308 null modem crossover adapter (with two 25-pin receptacle connectors) Once you have the appropriate equipment, complete the following steps: Power on and configure the console, using the parameters in...

  • Page 52: Connecting A Pc Console

    Attach the 25-pin receptacle connector on the combined cable and adapter to the console host connector 100-240~ 1.2A 50-60Hz Figure 1-15. Insert the 9-pin receptacle end of the console cable into the ARN console port connector. The console is now connected to the ARN. Connecting a PC Console You need both pieces in the ARN console/modem cable kit to connect a PC: •...
  • Page 53 Power off the PC console. Insert the 9-pin receptacle end of the console cable into the console port (Figure Attach the null modem crossover adapter to the other end of the console cable (refer to Redundant Power 100-240~ 1.2A 50-60Hz Figure 1-16.

  • Page 54: Connecting A Modem

    Connecting a Modem You can connect a modem to the ARN using the back-panel modem port or you can connect a telephone line directly to an optional, back-panel V.34 modem adapter module. Note: To use the Netboot, Directed Netboot, or Local Boot software configuration options, you must connect a console the first time you power up the ARN.
  • Page 55 Table 1-4. Modem Signal/Parameter Synchronous/Asynchronous Mode AutoAnswer Local Character Echo Supervisory Functions Baud Rate Data Bits Stop Bits Parity Refer to the modem user guide for instructions. Power off the modem. Insert the 9-pin receptacle end of the modem cable into the front-panel console port Redundant Power 100-240~...

  • Page 56: Connecting To A V.34 Modem Module

    Connecting to a V.34 Modem Module If your ARN contains an optional, back-panel V.34 modem module, you need only connect the telephone line to the V.34 interface for access to the router. Note: The default settings for the back-panel V.34 modem differ from the default settings for the front-panel V.34 modem adapter module.

  • Page 57: Connecting The Power Cable

    Connecting the Power Cable Complete these steps to connect the power cable: Connect the power cable to the power connector on the ARN back panel (Figure Danger: Be sure that the power switch is in the OFF (0) position before you connect the power cable.

  • Page 58: Installing The Flash Memory Card

    Installing the Flash Memory Card A PCMCIA Flash memory card Nonvolatile File System (NVFS) in the ARN. When you remove a formatted memory card, the NVFS automatically removes access to the card. When you insert and format a card or insert an already formatted card, the NVFS automatically provides access.

  • Page 59: Where To Go Next

    100-240~ 1.2A 50-60Hz Figure 1-20. Inserting the Flash Memory Card in the ARN Receptacle Where to Go Next Use the following table to determine where you want to go next. For information about Starting the ARN Operating the ARN Configuring the ARN for Netboot and Directed Netboot Using Local Boot (the Quick-Start Procedure) ARN Technical Specifications...

  • Page 61: Starting The Arn

    The first time you start the ARN, you complete an important software configuration process -- you provide the ARN with the files it needs to operate over the network. This chapter discusses the need for these specific startup files, what methods you can use to ensure that the router installs and uses the appropriate files, and how to use each of these installation methods.

  • Page 62: Understanding The Arn Boot Options

    You must complete an initial startup procedure to obtain the executable and default configuration files and connect the ARN to the network. Getting a file over the network is called network booting, or netbooting. Getting a file from the ARN file system, stored in Flash memory, is called local booting.
  • Page 63 Table 2-1. Summary of Initial Startup Options Source for Boot Source for Configuration Option Image file File Directed Local Local Netboot† Network Network Local Boot Local Local *. The ARN supports netboot over serial, Ethernet, token ring, and DSU/CSU interfaces only. †.

  • Page 64: Starting The Arn For The First Time

    Starting the ARN for the First Time The ARN factory defaults are set to find the configuration and image files from the following locations: • Configuration file -- over the network • Image file -- on the local PCMCIA Flash memory card These default settings work with the default EZ-Install procedure.

  • Page 65: Using Ez-Install

    Using EZ-Install EZ-Install is the default installation option. This option requires that your network administrator has set up the network so that you can start the EZ-Install procedure. In addition, this option requires that you • Install a Flash memory card. •...

  • Page 66: Using Netboot, Directed Netboot, Or Local Boot

    Using Netboot, Directed Netboot, or Local Boot You must use a command line interface that accesses the router software when you netboot or local boot the ARN. To use a command line interface, you can • Wait for the ARN to local boot (that is, wait for the router to fail EZ-Install and then attempt to boot using its local configuration file).

  • Page 67: Logging In To The Command Line Software

    While the router is running the EZ-Install procedure, issue a break sequence from the management console. The ARN monitor login prompt appears. Note: Be sure to issue a break sequence before the boot process completes. Break sequences can vary, depending on the console equipment type. Some console terminals have specific break keys on their keyboards;...

  • Page 68: Continuing With Netboot

    Continuing with Netboot Note: Continuing with the netboot option requires that you have already logged in to the Technician Interface or ARN monitor command line software. Refer to the previous section, “Logging in to the Command Line Software,” for instructions. You must have at least one serial, Ethernet, or token ring interface connected to the network to use the netboot option.
  • Page 69 To use the netboot option: Enter the prompt and press the Return key. The following is a sample command: ifconfig com1 9.0.0.2 255.0.0.0 9.0.0.3 Refer to Appendix A for more information about the Enter the following command and press the Return key to verify the configuration you specified in Step 1: getcfg getcfg...
  • Page 70 If getcfg displays the correct information, continue to the next step. Otherwise, reenter the correct administrator if you need assistance. Enter the following command and press the Return key to boot the ARN: boot Your console displays messages indicating the progress of the netboot procedure.

  • Page 71: Continuing With Directed Netboot

    Continuing with Directed Netboot Note: Continuing with the directed netboot option requires that you have already logged in to the Technician Interface or ARN monitor command line software. Refer to the previous section, “Logging in to the Command Line Software,” for instructions. You must have at least one serial, DSU/CSU, Ethernet, or token ring interface connected to the network to use the directed netboot option.
  • Page 72 bconfig directed netboot, the location must includes the following information: • The source of the image and configuration files (local or network) • The address of the TFTP server • The full directory path description locating the files on the TFTP server Write the commands in Table 2-4.
  • Page 73 Type the following command and press the Return key to verify the configuration you specified in Step 3: getcfg getcfg configuration file, the interface configuration that you specified using the ifconfig you specified using the Verify the interface configuration, as shown in $ getcfg Boot Options Netboot Parameters:...
  • Page 74 Note: If the ARN cannot find a software image or configuration file using the directed netboot procedure, it attempts to netboot once. If the netboot procedure fails, the ARN tries to local boot once. If all three boot attempts fail, the ARN continues to try directed netboot, netboot, and local boot until it boots successfully.

  • Page 75: Continuing With Local Boot (The Quick-Start Procedure)

    Continuing with Local Boot (the Quick-Start Procedure) Note: Continuing with the local boot option requires that you have already logged in to the Technician Interface or ARN monitor command line software. Refer to the previous section, “Logging in to the Command Line Software,” for instructions.
  • Page 76 Ensure that the ARN boots correctly. When the ARN boots, its LEDs flash in a particular order. See Chapter 3 for information on checking the ARN front-panel LEDs to ensure that the installation was successful and that the router is operating properly. After the ARN boots using its local software image and configuration file, the Technician Interface login prompt appears.

  • Page 77: Where To Go Next

    Contact your local Bay Networks Technical Response Center if you need additional assistance. After configuring the ARN network interface, you can replace the console connection with a modem connection to enable remote dial-in access. Where to Go Next Use the following table to determine where you want to go next. For information about Installing the ARN Operating the ARN...

  • Page 79: Operating The Arn

    This chapter describes how to • Locate and understand the function of base module LEDs • Use the expansion module and adapter module LEDs to check the status of various interfaces • Ensure a successful installation using the base module LEDs •...

  • Page 80: Led Descriptions

    LED Descriptions LEDs on the ARN front and back panels provide information about how the ARN is operating. The following sections describe the LEDs on the ARN base modules, expansion modules, adapter modules, and the ARN back panel. Base Module LEDs The ARN base module LEDs include diagnostic LEDs and either Ethernet or token ring interface LEDs.
  • Page 81 Table 3-1 describes the base module diagnostic LEDs. Table 3-1. Boot Fail Base Adapter1 Adapter2 Expansion PCMCIA 114200 Rev. A Base Module Diagnostic LEDs Meaning Flashes for 1 to 3 minutes, indicating that diagnostic tests are running. When it lights again and remains on, the ARN is operational.

  • Page 82: Ethernet Leds

    Ethernet LEDs Table 3-2 describes the base module Ethernet LEDs. Table 3-2. (Transmit) (Receive) (Collision) Token Ring LEDs Table 3-3 describes the base module token ring LEDs. Table 3-3. RCVR (Receiver) NSRT (Insert) WFLT (Wire Fault) Base Module Ethernet LEDs Meaning Lights when the Ethernet interface transmits data.

  • Page 83: Expansion Module Leds

    Expansion Module LEDs An ARN expansion module can contain Ethernet, token ring, or serial interface LEDs. Ethernet LEDs Table 3-4 describes the expansion module Ethernet LEDs. Table 3-4. (Transmit) (Receive) (Collision) Token Ring LEDs Table 3-5 describes the expansion module token ring LEDs. Table 3-5.

  • Page 84: Serial Leds

    Serial LEDs Table 3-6 describes the expansion module serial interface LEDs. Table 3-6. RLSD3 (Received Line Signal Detection 3) RLSD4 (Received Line Signal Detection 4) RLSD5 (Received Line Signal Detection 5) Adapter Module LEDs An ARN adapter module can contain serial, ISDN, DSU/CSU, or V.34 modem LEDs.

  • Page 85: Isdn Bri Leds (S/T Or U Interfaces)

    ISDN BRI LEDs (S/T or U Interfaces) Table 3-8 describes the ISDN adapter module LEDs. Table 3-8. S/T Interface Unlabeled LED U Interface (D-channel; 16-KB Management Channel) (Data Detect) (B-Channel #1; 64-KB Data Channel) (B-Channel #2; 64-KB Data Channel) DSU/CSU LEDs Table 3-9 describes the DSU/CSU adapter module LEDs.

  • Page 86: V.34 Modem Leds

    V.34 Modem LEDs Table 3-10 describes the V.34 modem adapter module LEDs. Table 3-10. (Transmit) (Receive) RLSD (Received Line Signal Detection) (Data Terminal Ready) Back-Panel LEDs The ARN back-panel allows for an optional V.34 Modem Adapter module. Refer to the previous section, “V.34 Modem LEDs,” for more information about these LEDs.

  • Page 87: Ensuring A Successful Installation

    Ensuring a Successful Installation After connecting the ARN to the network, you can ensure a successful installation by checking the diagnostic LEDs on the front panel of the base module (refer to Figure 3-1). When you power on the ARN, the following sequence of front panel LED activity should occur: •...

  • Page 88: Powering On And Off The Arn

    If the LEDs do not light in this sequence, your network administrator can refer to Configuring Remote Access to help troubleshoot the problem. Note: If the ARN does not contain an expansion module, an adapter module, a redundant power supply, a data collection module, or a Flash card, the LEDs associated with these components remain off.

  • Page 89: Resetting The Arn

    Resetting the ARN The Reset button is set inside the ARN back panel and resides next to the Flash card slot, as shown in Figure 3-3. 100-240~ 1.2A 50-60Hz Figure 3-3. ARN Reset Button To press the Reset button, insert a small pointed object (for example, a paper clip) into the Reset button hole.

  • Page 90: Removing A Flash Memory Card

    Removing a Flash Memory Card To remove a memory card from an ARN: Press the Eject button next to the card receptacle on the back panel. Pull the memory card out of the card receptacle. Figure Caution: Do not remove the Flash memory card while the router is operating. Removing the memory card interferes with current networking operations.

  • Page 91: Protecting Memory Card Files

    Protecting Memory Card Files Bay Networks ships each memory card with its Read/Write Protect switch in the unprotected position and saving your configuration, you may want to write-protect the memory card for backup purposes. Note: You typically do not operate the ARN with a write-protected memory card.

  • Page 92: Where To Go Next

    Where to Go Next Use the following table to determine where you want to go next. For information about Installing the ARN Starting the ARN Configuring the ARN for Netboot and Directed Netboot Using Local Boot (the Quick-Start Procedure) ARN Technical Specifications 3-14 Go to Chapter 1...

  • Page 93: Configuring The Arn For Netboot And Directed Netboot

    Configuring the ARN for Netboot and The following commands configure the ARN for netboot and directed netboot: Use the i • network. You need this information to complete the procedure in “Continuing with Netboot” in Chapter 2. • Use the software image and configuration file.

  • Page 94: Configuring An Ip Serial Or Dsu/Csu Interface For Netbooting

    • Enable or disable netbooting on an interface. The following sections describe each use of the Configuring an IP Serial or DSU/CSU Interface for Netbooting Configure a serial or DSU/CSU (COM) interface to the IP network using the following interface configuration command: ifconfig [ synchronous options ] <interface>...
  • Page 95 Table A-1. Setting -annexd -annexa -lmi -int_clk <interface> <IP address> <subnet mask> <next hop address> 114200 Rev. A ifconfig Command Settings for a COM Interface Description Frame Relay Settings Configures the router COM interface as a Frame Relay connection. With this setting, use one of the following options to specify a DLCMI setting: -annexd, -annexa, or -lmi.

  • Page 96: Configuring An Ethernet Interface For Network Booting

    Configuring an Ethernet Interface for Network Booting To configure an ARN Ethernet interface for network booting, use the following command format: ifconfig Table A-2 describes the Ethernet interface. Table A-2. Setting <interface> <IP address> <subnet mask> <next hop address> <interface> [ <IP address> <subnet mask> [ <next hop address> ]] command arguments for configuring the router’s ifconfig ifconfig Command Settings for an Ethernet Interface...

  • Page 97: Configuring A Token Ring Interface For Network Booting

    Configuring a Token Ring Interface for Network Booting To configure an ARN token ring interface for network booting, use the following command format: ifconfig address> ]] Table A-3 describes the token ring interface. Table A-3. Setting <speed> <interface> <IP address> <subnet mask>...

  • Page 98: Enabling And Disabling Interfaces With Ifconfig

    Enabling and Disabling Interfaces with ifconfig To enable or disable an ARN interface for the network boot process, use the following command formats: ifconfig -disable <interface> ifconfig -enable <interface> Table A-4 describes the interfaces for network booting. Table A-4. Setting <...

  • Page 99: Using The Bconfig Command

    Using the bconfig Command To use netboot, you use the configuration file or software image resides on the network. To use directed netboot, you use the the full pathname to the software image and configuration file. To use local boot, you use the image both reside on the local file system (that is, the PCMCIA Flash card).

  • Page 100: Bconfig Command Examples

    bconfig Command Examples 1. Configure the default netboot procedure -- use a local image file and look for the configuration file over the network using BootP. bconfig -d image bconfig -d config 2. Use netboot for both the boot image and configuration file. bconfig image network bconfig config network 3.
  • Page 101 The following sample response shows the settings for an ARN with one Ethernet, one token ring, and five serial interfaces: Boot Options boot image=local boot config=network Netboot Parameters: MAU1...None XCVR2..None COM1...EZ-Install COM2...EZ-Install COM3...EZ-Install COM4...EZ-Install COM5...EZ-Install 114200 Rev. A...

  • Page 103: Using Local Boot (The Quick-Start Procedure)

    Appendix B Using Local Boot (the Quick-Start Procedure) This appendix explains how to local boot the ARN using the Quick-Start procedure. The Quick-Start Procedure is the initial configuration that gets a Bay Networks ARN router up and running on the network. The procedure enables the Internet Protocol (IP) so that the router can connect to Site Manager.

  • Page 104: Understanding Quick-Start Connector Names And Numbers

    Understanding Quick-Start Connector Names and Numbers The Quick-Start script assigns a name and number to each interface, depending on its location on the ARN. In addition to either an Ethernet or token ring base module, the ARN can contain expansion modules and adapter modules ISDN BRI withNT1 RLSD...

  • Page 105: Filling Out The Worksheets

    Filling Out the Worksheets The inst_arn.bat script provides many options for configuring the ARN on a network. Since typical remote access uses a serial interface over a wide area connection, this section lists only the options involved with a serial configuration. Note: This section provides worksheets only for a serial interface configuration over a wide area connection.

  • Page 106: Global Information Worksheet

    Global Information Worksheet This section contains the prompts and possible options relating to all ARN serial configurations. Write your selection in the “Your Response” column. Global Information Worksheet Step Requested Information Enter the module number [1]: Driver Type: Options The script lists the available modules that you can use to connect the router’s IP network interface to Site Manager.
  • Page 107 Global Information Worksheet Step Requested Information Enter connector number [1]: Enter clock source number [2]: Enter clock speed number [10]: Enter circuit name [S#]: 114200 Rev. A (continued) Options If there is only one connector on the module you chose, the script automatically assigns a connector number and bypasses this prompt.
  • Page 108 Global Information Worksheet Step Requested Information Enter IP address in dotted decimal notation: Enter IP subnetwork mask in dotted decimal notation: Is the router connected to the same local area network as the Site Manager workstation? (y/n) [n]: Enter routing protocol number [1]: Enter wide area protocol number [1]:...

  • Page 109: Router Protocol Worksheets

    Global Information Worksheet Step Requested Information Do you want to enable TI TELNET (y/n) [n]: Do you wish to save this configuration to a file? (y/n) [y] Enter filename [ startup.cfg ]: Do you wish to set up another port/module? (y/n) [y] Router Protocol Worksheets This section contains requested information and possible options relating to the routing protocol choices on the Global Worksheet.
  • Page 110 OSPF Worksheet Requested Information Enter OSPF router ID in dotted decimal notation: Enter the OSPF area ID in dotted decimal notation [0.0.0.0]: Enable Simple Password authentication? (y/n) [n]: Follow default paths for unknown subnets? (y/n) [n]: Enter OSPF MTU size selection [1]: Options Enter an IP address to uniquely identify the router in the OSPF...
  • Page 111 OSPF Worksheet (continued) Requested Information Enter OSPF interface type selection [1]: Enter decimal value in seconds for Hello Interval [10]: Note: This value must match all other interfaces in the OSPF area for connection to take place. Enter decimal value in seconds for Router Dead Interval [40]: Note: This value must match all other interfaces in the OSPF area for...
  • Page 112 OSPF Worksheet (continued) Requested Information Enter decimal value in seconds for Poll Interval [20]: (For NBMA only) Enter IP address of neighbor in dotted decimal notation or enter q to quit: (For NBMA only) Enter IP address of neighbor in dotted decimal notation: (For PPP only) Static Route to Site Manager Worksheet...

  • Page 113: Wide Area Protocol Worksheets

    Static Route to Site Manager Worksheet Requested Information Follow the default route for unknown subnets? (y/n) [n]: Wide Area Protocol Worksheets This section contains requested information and possible options relating to wide area protocol choices on the Global Worksheet. Bay Networks Proprietary PPP Worksheet Requested Information Enter BofL (Breath of Life) timer value (1-60) [5]:...
  • Page 114 Bay Networks Proprietary PPP Worksheet Requested Information Enter Remote Address selection [3]: Frame Relay Worksheet Requested Information Enter Management type [3]: Enter addressing type [4]: Enter address field length [2]: Enter DLCI number [30]: (For DLCMI None, LMI Switch, Annex D Switch, and Annex A Switch only) B-12 (continued)
  • Page 115 PPP Standard Worksheet Requested Information Enter Remote IP address in dotted decimal notation: Do you wish to turn on the PPP echo function? (y/n) [n]: Enable PAP (Password Authentication Protocol)? (y/n) [n]: Enable CHAP (Challenge Handshake Authentication Protocol)? (y/n) [n]: Does the Remote Peer have PAP authentication enabled? (y/n) [n]: Enable the LQR (Link Quality...
  • Page 116 PPP Standard Worksheet Requested Information Enable use of the Remote Peer router’s LQR Timer? (y/n) [y]: (For LQR Protocol only) Number of seconds (1-120) [3]: (For LQR Protocol only) Enter [inbound] success rate percentage (1-100) [90]: Enter [outbound] success rate percentage (1-100) [90]: B-14 (continued)

  • Page 117: Running The Quick-Start Script

    SMDS Worksheet Requested Information Enter 10-digit individual address: Enter 10-digit group address: Enter 10-digit arp address: Running the Quick-Start Script You run the inst_arn.bat script as part of the Local Boot process. Note: Make sure that you have the completed worksheets with you. Begin local boot as follows: At the Technician Interface Enter...
  • Page 118 Type the following command and press the return key: run inst_arn.bat Follow the script online, using your worksheets when responding to its prompts. Refer to the list of commands in Table B-2. Task Accept a default value Repeat a step (for example, if you make a mistake) Stop the Quick-Start...

  • Page 119: Technician Interface

    Name and save the configuration file. The script begins to test the configuration on the new IP interface (Figure Testing local IP interface ping -IP 192.32.00.000 -r5 IP ping: IP ping: IP ping: IP ping: IP ping: This test attempts to ping the Site Manager workstation. NOTE: If routing has not yet converged, an attempt to ping the Site Manager workstation may fail.

  • Page 121: Technical Specifications

    This appendix provides technical specifications and a product overview of the ARN and its interface options. This appendix lists • Physical, electrical, and environmental specifications • Hardware communications options • BayStack ARN configurations Physical Specifications The dimensions and weight of the ARN are as follows: •...

  • Page 122: Electrical Specifications

    If you are installing your ARN in an electronic enclosure rack, make sure that the rack meets the following specifications: • Heavy-duty steel construction • Electronic Industries Association (EIA) standard hole-spacing • Width of 19 in. (48.26 cm) • Depth of 24 in. (60.96 cm) Electrical Specifications Your installation site must meet the following power requirements: •...

  • Page 123: Hardware Communications Options

    Hardware Communications Options The ARN is designed to scale to your needs. In addition to either an Ethernet or token ring base module, you can add an optional expansion and up to two optional adapter modules to the ARN. The ARN is available in the following base module configurations: •...
  • Page 124 Table C-2 describes each interface. Table C-2. Network Interfaces Available on ARNs Network Interface Description Ethernet and Supports the Ethernet and IEEE 802.3 standards that provide LAN connectivity. The Second Ethernet ARN can have up to two Ethernet interfaces -- one on the base module and one on an expansion module.

  • Page 125: Ethernet Attachment Unit Interface (Aui

    Note: Refer to the Cable Guide for Routers and BNX Platforms for the proper cables or cable pinouts to use for each interface type. Ethernet Attachment Unit Interface (AUI) The ARN Ethernet base module, Ethernet expansion module, and Ethernet/tri-serial expansion modules contain a 10Base-T standard 802.3 AUI DB-15 receptacle with a slide lock.

  • Page 126: Ethernet 10Base-T Interface

    Ethernet 10Base-T Interface The Ethernet 10Base-T interface provides UTP support. pin locations and function assignments for the 10Base-T interface. Table C-4. Pin Assignment 12345678 10Base-T Interface Pin Assignments Pin No. Signal (Function) TD+ (Transmit to UTP wire) TD- (Transmit to UTP wire) RD+ (Receive from UTP wire) Not used Not used...

  • Page 127: Token Ring Stp Interface

    Token Ring STP Interface The token ring STP interface provides shielded twisted-pair support. The ARN token ring base module, token ring expansion module, and token ring/tri-serial expansion modules contain this standard 802.5 DB-9 receptacle. Table C-5 shows the pin assignments for the standard 9-pin STP receptacle on the ARN base or expansion module and identifies its pin locations.

  • Page 128: Token Ring Utp Interface

    Token Ring UTP Interface The token ring UTP interface provides unshielded twisted-pair support. The ARN token ring expansion module, and token ring/tri-serial expansion modules contain this receptacle. Table C-6 shows the RJ-45 pin assignments for the UTP interface and identifies the pin locations.
  • Page 129 • RS-232 connections • RS-530 connections Table C-7 shows the signal and pin assignments for these connectors. Table C-7. Serial Interface Pin Assignments Pin Assignment Pin 15 Pin 30 Pin 44 114200 Rev. A Order No. 7826 Order No. AE0018012 Pin No.

  • Page 130: Isdn Bri U Interface

    ISDN BRI U Interface The ARN supports the BRI standard for ISDN using an optional ISDN/BRI adapter module. The integrated ISDN BRI functionality allows you to connect directly to the ISDN network, through a U interface, as opposed to connecting over a terminal adapter.

  • Page 131: Isdn Bri S/T Interface

    ISDN BRI S/T Interface The ARN supports the BRI standard for ISDN using an optional ISDN/BRI adapter module. The integrated ISDN BRI functionality allows you to connect to the ISDN network over a terminal adapter through an S/T interface. The BRI implementation supports two dial service applications: dial-on-demand and dial backup.

  • Page 132: 56/64K Dsu/Csu Interface

    56/64K DSU/CSU Interface The ARN supports DSU/CSU connectivity using an optional DSU/CSU adapter module. The integrated DSU/CSU functionality allows you to connect directly to a dataphone digital service (DDS) line. This solution reduces equipment costs and simplifies connection to a wide area network. Table C-10 lists the DSU/CSU interface pin assignments.

  • Page 133: Interface (For V.34 Modem

    RJ-11 Interface (for V.34 Modem) The ARN supports a V.34 modem connection using an optional V.34 modem adapter module. The V.34 functionality allows you to connect directly to a phone line, as opposed to connecting over an external modem. This solution reduces equipment costs and simplifies connection to a wide area network.

  • Page 134: Service Modem Connections

    The connector pin assignment described in assignments for the console port. Table C-12. Pin Assignment Pin 1 Service Modem Connections The ARN back panel contains one modem service interface, labeled Modem; its DB-9 plug connector provides an RS-232-D serial connection. You use this local console port to connect the ARN to any Hayes compatible modem for remote dial-in access.
  • Page 135 The connector pin assignment described in assignments for the modem port. Table C-13. Pin Assignment Pin 1 114200 Rev. A Table C-13 Service Modem Port DB-9 Pin Assignments Pin No. Signal Name DCD (Data carrier detect) TXD (Transmit data) RXD (Receive data) DSR (Data set ready) DTR (Data terminal ready) Pin 9...

  • Page 137: Requirements For European Operation

    Requirements for European Operation This appendix provides information required for operating the ARN in Europe, cabling requirements for synchronous (serial) connection, and information about using the serial adapter module (Order No. CV0004001) and ISDN BRI adapter module (Order No. CV0004002) in Europe. ARN Ethernet Base Model Safety Status Table D-1 lists the safety status of interconnection points to the connection of...

  • Page 138: Arn Token Ring Base Model Safety Status

    ARN Token Ring Base Model Safety Status Table D-2 lists the safety status of interconnection points to the connection of other equipment. Table D-2. Port Location Console ARN Expansion Modules Safety Status Order Numbers CV0004011, CV0004012, CV0004013, CV0004014, CV0004015 are upgrade options that provide an additional synchronous interface. These options can be installed in any ARN model.

  • Page 139: Synchronous Cabling Requirements

    Synchronous Cabling Requirements Refer to Figures cabling information. Note the following compliance requirements: • V.28 compliance requires an Order No. 7837 cable. • V.35 compliance requires an Order No. 7220 cable. • X.21 compliance requires an Order No. 7224 cable. 44-position D-Sub plug with screw locks (ground shield connected to backshell) Figure D-1.
  • Page 140 Table D-4. WAN Interface (Order No. 7837) Bay Networks Termination Data Set Ready+ Data Terminal Ready+ Data Carrier Detect+ Send Timing+ Receive Timing+ Transmitter Signal Element Timing+ Signal Ground Pin 7 > 19 > 20 > 23 Pin 13 > 28 Pin 14 >...
  • Page 141 Table D-5. V.35 Interface (Order No. 7220) Bay Networks Termination Signal VSD+ VSD- VRT+ VRT- VST+ VST- VRD+ VRD- Data Set Ready+ Data Terminal Ready+ Request to Send+ Clear to Send+ VTT+ VTT- Frame Ground Data Carrier Detect+ Signal Ground Pin 19 >...
  • Page 142 Pin 1 Pin 16 Pin 31 44-position D-Sub plug with screw locks (ground shield connected to backshell) Figure D-3. Cable 7224 (X.21 Compliant) Table D-6. X.21 Interface (Order No. 7224) Bay Networks Termination Signal Send Data+ Send Data- Request to Send+ Request to Send- Receive Data+ Receive Data-...

  • Page 143: Serial Adapter Module Requirements

    Serial Adapter Module Requirements The Serial Adapter module (Order No. CV0004001) is approved only for installation in a host, and with host attachments, which are either type approved for such apparatus or, if supplied after 1st March 1989, are marked with or supplied with a statement that the host is supplied under the terms of General Approval Number NS/G/1234/J/100003.

  • Page 144: Isdn Bri Adapter Module Requirements

    ISDN BRI Adapter Module Requirements The ISDN BRI Adapter module (Order No. CV0004002) is approved only for installation in a host, and with host attachments, which are either type approved for such apparatus or, if supplied after 1st March 1989, are marked with or supplied with a statement that the host is supplied under the terms of General Approval Number NS/G/1234/J/100003.

  • Page 145: Clearance And Creepage Distances For Isdn Bri And Serial Adapter Modules

    Power Requirements for ISDN BRI and Serial Adapter Modules The ISDN BRI and serial adapter modules obtain power from the host chassis and have the power requirements shown in Table D-10. Voltage +5 V +12 V -12 V The power drawn from the host chassis combined with that required for any other cards and accessories must be within the power rating of the host chassis.
  • Page 146 SELV cards Figure D-4. Table D-11. Clearance (X) 2.0 mm 2.6 mm 4.0 mm 4.0 mm D-10 ISDN Module Baseboard Clearance and Creepage Distances for ISDN BRI and Serial Adapter Modules Clearance and Creepage Distances for ISDN BRI and Serial Adapter Modules Voltage used or generated by other parts Creepage (Y)
  • Page 147 The creepage distances apply to the normal office environment. When the local environment within the host chassis is subject to conductive pollution or dry nonconductive pollution that could become conductive due to condensation, the creepage distances shown in parentheses in The clearance and creepage distance between adjacent points should be checked as follows: •...
  • Page 149 Symbols 10Base-T interface, connecting to, 1-12 pin assignments, C-6 adapter modules connecting to DSU/CSU interfaces, 1-18 ISDN interfaces, 1-17 serial interfaces, 1-16 V.34 interface, 1-19 DSU/CSU LEDs, 3-7 interface options, 1-10, C-3 ISDN LEDs, 3-7 locating, 1-9 serial LED, 3-6 V.34 LEDs, 3-8 Adapter1 LED, 3-3 Adapter2 LED, 3-3...
  • Page 150 InfoFACTS service, xxix Proprietary PPP protocol, worksheet for, B-11 publications, ordering, xxiv Standard protocol, A-2 support programs, xxvi Support Source CD, xxviii Technical Response Center, xxv, xxix technical support, xxv B-channel #1 (B1) LED, 3-7 B-channel #2 (B2) LED, 3-7 bconfig command default netboot settings, A-8 described, 2-12...
  • Page 151 command line interface choice of, 2-6 logging in to, 2-7 CompuServe, Bay Networks forum on, xxviii config file default boot location, 2-4 defined, 2-1 local booting with, 2-15 using local, B-15 configuring DSU/CSU interfaces, A-2 Ethernet interfaces, A-4 serial interfaces, A-2 token ring interfaces, A-5 connecting 10Base-T cables, 1-12...
  • Page 152 DSU/CSU cables, connecting, 1-18 interfaces adapter module, 1-10 configuring, A-2 connecting to, 1-18 pin assignments, C-12 LEDs, 3-7 electrical specifications, C-2 electronic enclosure rack installing in, 1-6 specifications, 1-4, C-2 environmental specifications, C-2 Ethernet base module LEDs, 3-4 interface types 10Base-T, 1-9 AUI, 1-9 base module, 1-9...
  • Page 153 hardware for rack-mounting, 1-6 module options, C-3 requirements, 1-4 Hayes modem, 1-24 See also modem HDLC encapsulation, A-2 heat dissipation, requirements for preventing, 1-5, C-1 ifconfig command defined, 2-8 disabling interfaces with, A-6 enabling interfaces with, A-6 examples, A-6 using, A-1 to A-6 image, specifying location of, A-7 InfoFACTS service, xxix insert (NSRT) LED, 3-4, 3-5...
  • Page 154 expansion module Ethernet, 3-5 serial, 3-6 token ring, 3-5 startup sequence, 3-9 LMI, Frame Relay, A-2 local boot attaching a console for, 1-20 attaching a modem for, 1-24 bconfig command, A-8 defined, 2-2 requirements, 2-6 starting, B-15 using, 2-6 to 2-14, 2-15 to 2-17 local file system mounting, B-15 viewing, 2-16...
  • Page 155 power cables, 1-27 specifications, C-2 switch, 3-10 Power (Pwr) LED, 3-3 powering on the ARN, 3-10 PPP protocol, Bay networks proprietary, B-11 PPP wide area protocol, worksheet for, B-13 preparing for installation, 1-2 to 1-8 Quick-Start procedure commands, B-16 inst_arn.bat script, 2-16 running, 2-16, B-15 using, 2-16, B-16 worksheet, B-4 to B-7...
  • Page 156 European, D-1 to D-11 physical, C-1 Standard protocol, Bay Networks, A-2 startup options, displaying, A-8 cables, connecting, 1-13 interfaces connecting to, 1-13 pin assignments, C-7 Support Source CD, xxviii switch power, 3-10 read/write memory, 3-13 synchronous. serial Technician Interface, local booting with, 2-15 terminal console, connecting to, 1-21 terminal.

This manual is also suitable for:

Baystack arn

Table of Contents

Save PDF
