General Specifications
Line Power Supply 6 x 380–480V AC
Typical Shaft output at 400 V
[kW]
Typical Shaft output at 460 V
[HP]
Typical Shaft output at 480 V
[kW]
IP21/Nema 1 and IP54/Nema
12 Drive Types without/with
options cabinet
Output current
Continuous
(at 400 V) [A]
Intermittent (60 sec overload)
(at 400 V) [A]
Continuous
(at 460/ 480 V) [A]
Intermittent (60 sec overload)
(at 460/ 480 V) [A]
Continuous KVA
(at 400 V) [KVA]
Continuous KVA
(at 460 V) [KVA]
Continuous KVA
(at 480 V) [KVA]
Max. input current
Continuous
(at 400 V) [A]
Continuous (at 460/ 480 V) [A]
2
Max. cable size,motor [mm
(AWG 2) )]
Max. cable size, line power
2 2)
[mm (AWG )]
Max. cable size, brake [mm 2
2)
(AWG )
Max. external electrical fuses
[A] 1
Estimated power loss
at 400 V [W] 4)
Estimated power loss
at 460 V [W]
max. added losses A1 RFI, CB
or Disconnect, & contactor
Max. panel options losses
Weight,
Unit Size IP21, IP 54 [kg]
Weight Rectifier Module [kg]
Weight Inverter Module [kg]
Efficiency 4)
Output frequency
Heatsink overtemp. trip
Power card ambient trip
* Heavy Duty = 160% torque during 60 sec., Light Duty = 110% torque during 60 sec.
VLT AQUA 12-Pulse High Power Instruction Manual
650 HP 750 HP
500 560
650 750
560 630
F10/F11 F10/F11
880 990
968 1089
780 890
858 979
610 686
621 709
675 771
857 964
759 867
8x150
(8x300 mcm)
4x185
(4x350 mcm)
900
10647 12338
9414 11006
963 1054
1004/ 1299 1004/ 1299
102 102
102 102
®
