Danfoss VLT AQUA Drive FC 200 Instruction Manual page 83

How to program the adjustab...
[120] Lead Pump
Start
[121] Lead Pump
Alternation
[130 Pump1
6 6
- Interlock -
138] Pump9
Interlock
6-20
VLT AQUA 12-Pulse High Power Instruction Manual
Starts/stops the lead pump (controlled by
the adjustable frequency drive). A start
requires that also a System Start signal has
been applied, e.g., to one of the digital
inputs set for Start [8]!
Forces alternation of the lead pump in a
cascade controller. Lead Pump Alternation,
25-50 Lead Pump Alternation must be set to
either At Command [2] or At Staging or At
Command [3]. Alternation Event,
25-51 Alternation Event can be set to any of
the four options.
The function will depend on the setting in
25-06 Number Of Pumps. If set to No [0],
then Pump1 refers to the pump controlled
by relay RELAY1 etc. If set to Yes [1], Pump1
refers to the pump controlled by the
adjustable frequency drive only (without
any of the built-in relays involved) and
Pump2 to the pump controlled by the relay
RELAY1. Variable speed pump (lead) cannot
be interlocked in the basic cascade
controller.
See table below:
Setting in Setting in 25-06 Number Of
Par. 5-1* Pumps
[0] No
[130] Pump1 Controlled Adjustable
Interlock by RELAY1 frequency
(only if not
lead pump) controlled
(cannot be
interlocked)
[131] Pump2 Controlled Controlled by
Interlock by RELAY2
[132] Pump3 Controlled Controlled by
Interlock by RELAY3
[133] Pump4 Controlled Controlled by
Interlock by RELAY4
[134] Pump5 Controlled Controlled by
Interlock by RELAY5
[135] Pump6 Controlled Controlled by
Interlock by RELAY6
[136] Pump7 Controlled Controlled by
Interlock by RELAY7
[137] Pump8 Controlled Controlled by
Interlock by RELAY8
[138] Pump9 Controlled Controlled by
Interlock by RELAY9
MG.20.Y1.22 - VLT
5-13 Terminal 29 Digital Input
Option:
[0] No Operation Same options and functions as parameter
*
E-05 Terminal 32 Digital Input
Option:
[0] No Operation Same options and functions as parameter
*
E-06 Terminal 33 Digital Input
Option:
[0] No Operation Same options and functions as parameter
*
5-30 Terminal 27 Digital Output
Same options and functions as parameter group 5-3*.
Option:
[0]
*
5-40 Function Relay
Option:
[1] Yes
[0] No operation
*
drive
[1] Control ready
[2] Drive ready
[3] Drive rdy/rem ctrl
[4] Enable / no warning
[5] VLT running
RELAY1
[6] Running / no warning
[7] Run in range/no warn
RELAY2
[8] Run on ref/no warn
[9] Alarm
RELAY3
[10] Alarm or warning
[11] At torque limit
RELAY4
[12] Out of current range
[13] Below current, low
RELAY5
[14] Above current, high
[15] Out of speed range
RELAY6
[16] Below speed, low
[17] Above speed, high
RELAY7
[18] Out of feedb. range
RELAY8 [19] Below feedback, low
[20] Above feedback, high
[21] Thermal warning
[22] Ready,no thermal W
[23] Remote,ready,no TW
®
is a registered Danfoss trademark
Function:
group 5-1* Digital Inputs.
Function:
group E-0# and E-5# Digital Inputs, except
for Pulse input.
Function:
group E-0# and E-5# Digital Inputs.
Function:
No operation
Function:
Select options to define the
function of the relays.
The selection of each mechanical
relay is realized in an array
parameter.
