Mechanical Installation
Terminal locations - Unit Sizes 61 and 63
Figure 3.11 Terminal locations - Inverter Cabinet (front, left and right side view). The connector plate is 1.65 in [42 mm] below .0 level.
1) Ground bar
2) Motor terminals
3) Brake terminals
VLT AQUA 12-Pulse High Power Instruction Manual
1
2
3
®
