Danfoss VLT AQUA Drive FC 200 Instruction Manual page 74

How to program the adjustab...
0-37 Display Text 1
Range: Function:
0 [0 - In this parameter, it is possible to write an
N/A 0 individual text string for display in the LCP or to be
*
N/A] read via serial communication. If it is to be
displayed permanently, select Display Text 1 in
0-20 Display Line 1.1 Small, 0-21 Display Line 1.2
Small, 0-22 Display Line 1.3 Small, 0-23 Display Line 2
Large or 0-24 Display Line 3 Large. Use the [
▼
[ ] buttons on the LCP to change a character. Use
◀ ▶
the [ ] and [ ] buttons to move the cursor. When
a character is highlighted by the cursor, it can be
changed. Use the [
change a character. A character can be inserted by
placing the cursor between two characters and
▲ ▼
pressing [ ] or [
0-38 Display Text 2
Range: Function:
0 [0 - In this parameter, it is possible to write an
N/A 0 individual text string for display in the LCP or to
*
N/A] be read via serial communication. If to be
displayed permanently select Display Text 2 in
0-20 Display Line 1.1 Small, 0-21 Display Line 1.2
Small, 0-22 Display Line 1.3 Small, 0-23 Display Line
2 Large or 0-24 Display Line 3 Large. Use the [
▼
[ ] buttons on the LCP to change a character. Use
◀ ▶
the [ ] and [ ] buttons to move the cursor. When
a character is highlighted by the cursor, this
character can be changed. A character can be
inserted by placing the cursor between two
characters and pressing [
0-39 Display Text 3
Range: Function:
0 [0 - In this parameter, it is possible to write an
N/A 0 individual text string for display in the LCP or to be
*
N/A] read via serial communication. If it is to be
displayed permanently, select Display Text 3 in
0-20 Display Line 1.1 Small,0-21 Display Line 1.2
Small, 0-22 Display Line 1.3 Small, 0-23 Display Line 2
Large or 0-24 Display Line 3 Large. Use the [
▼
[ ] buttons on the LCP to change a character. Use
◀ ▶
the [ ] and [ ] buttons to move the cursor. When
a character is highlighted by the cursor, this
character can be changed. A character can be
inserted by placing the cursor between two
characters and pressing [
VLT AQUA 12-Pulse High Power Instruction Manual
▲
] or
▲ ▼
] or [ ] buttons on the LCP to
].
▲
] or
▲ ▼
] or [ ].
▲
] or
▲ ▼
] or [ ].
®
MG.20.Y1.22 - VLT is a registered Danfoss trademark
0-70 Date and Time
Range:
Size related [0–0 ]
*
0-71 Date Format
Option: Function:
[0] YYYY-MM-DD Sets the date format to be used in the LCP.
*
[1] DD-MM-YYYY Sets the date format to be used in the LCP.
[2] MM/DD/YYYY Sets the date format to be used in the LCP.
0-72 Time Format
Option: Function:
Sets the time format to be used in the LCP.
[0] 24 h
*
[1] 12 h
0-74 DST/Summertime
Option: Function:
Choose how Daylight Saving Time/Summertime
should be handled. For manual DST/Summertime
enter the start date and end date in 0-76 DST/
Summertime Start and 0-77 DST/Summertime End.
[0] OFF
*
[2] Manual
0-76 DST/Summertime Start
Range: Function:
0 N/A [0 - 0 N/A] Sets the date and time when
*
summertime/DST starts. The date is
programmed in the format selected in
0-71 Date Format.
0-77 DST/Summertime End
Range:
0 N/A [0 - 0 N/A]
*
6.2.2 General Settings
Define whether the adjustable frequency drive operates in
open-loop or closed-loop.
