How to Install
4 4
Figure 4.2 Rectifier and Inverter Cabinet, unit sizes 61, 62, 63 and 64.
1) 12-pulse rectifier module
2) Ground PE Terminals
3) Line / Fuses
R1 S1
L1-1 L2-1 L3-1
91-1 92-1 93-1
4) Line / Fuses
R2 S2
L2-1 L2-2 L3-2
91-2 92-2 93-2
4-4
VLT AQUA 12-Pulse High Power Instruction Manual
1
2
5) Motor connection
U
T1 T2
T1 96 97
6) Brake Terminals
-R +R
81 82
T2 7) Inverter Module
8) SCR Enable / Disable
9) Relay 1
01 02
10) Auxillary Fan
104 106
MG.20.Y1.22 - VLT
10
3
V W
T3
98
Relay 2
03 04 05 06
®
