How to Read the Instruction...
1 1
- Application Note MN20B102: Master/Follower
Operation Application
- Application Note MN20F102: Drive Closed-loop
and Sleep Mode
- Instruction MI.38.Bx.yy: Installation Instruction for
Mounting Brackets Enclosure type A5, B1, B2, C1
and C2 IP21, IP55 or IP66
- Instruction MI.90.Lx.yy: Analog I/O Option
MCB109
1.1.5 Abbreviations and Standards
Table 1.1 Abbreviation and Standards table
1-2
VLT AQUA 12-Pulse High Power Instruction Manual
Abbreviations: Terms:
a Acceleration
AWG American wire gauge
Auto Tune Automatic Motor Tuning
°C
Celsius
I Current
I Current limit
LIM
DCT Drive Control Tool
Joule Energy
°F
Fahrenheit
f Frequency
kHz Kilohertz
mA Milliampere
ms Millisecond
min Minute
M-TYPE Motor Type Dependent
Nm Newton meters
I
Nominal motor current
M,N
f Nominal motor frequency
M,N
P
Nominal motor power
M,N
U Nominal motor voltage
M,N
par. Parameter
PELV Protective Extra Low Voltage
Watt Power
Pascal Pressure
I Rated Drive Output Current
INV
RPM Revolutions Per Minute
SR Size Related
T Temperature
t Time
T Torque limit
LIM
U Voltage
MG.20.Y1.22 - VLT
- Instruction MI.33.Hx.yy: Panel through mount kit
x = Revision number
yy = Language code
Danfoss technical literature is also available online at
www.danfoss.com/BusinessAreas/DrivesSolutions/Documen-
tations/Technical+Documentation.htm.
®
is a registered Danfoss trademark
SI units: I-P units:
m/s 2 ft/s 2
A Amp
J = N∙m ft-lb, Btu
Hz Hz
kHz kHz
in-lbs
W Btu/hr, hp
Pa = N/m² psi, psf, ft of water
C F
s s, hr
V V
