How to Install
4 4
Figure 4.4 Inverter Cabinet, unit sizes 61 and 63.
1) External Temperature Monitoring
2) AUX Relay
01 02
04 05
3) NAMUR
4) AUX Fan
100 101 102 103
L1 L2
5) Brake
-R +R
81 82
4-6
VLT AQUA 12-Pulse High Power Instruction Manual
3
7
4, 8, 9
5
6
03
06
L1 L2
MG.20.Y1.22 - VLT
1
FASTENER TORQUE: M8 9.6 NM (7 FT-LB) FASTENER TORQUE: M8 9.6 NM (7 FT-LB)
-R 81 +R 82 -R 81 +R 82
FASTENER TORQUE: M10 19 Nm (14 FT-LB) FASTENER TORQUE: M10 19 Nm (14 FT-LB)
U/T1 96 V/T2 97 W/T3 98 U/T1 96 V/T2 97 W/T3 98
6) Motor
U V W
96 97 98
T1 T2 T3
7) NAMUR Fuse. See fuse tables for part numbers
8) Fan Fuses. See fuse tables for part numbers
9) SMPS Fuses. See fuse tables for part numbers
®
