Danfoss VLT AQUA Drive FC 200 Instruction Manual page 85

How to program the adjustab...
6-01 Live Zero Timeout Function
Option:
6 6
[0] Off
*
[1] Freeze
output
[2] Stop
[3] Jogging
[4] Max.
speed
[5] Stop and
trip
6-10 Terminal 53 Low Voltage
Range:
0.07 V [0.00 - par.
*
6-11 V]
6-11 Terminal 53 High Voltage
Range:
10.00 V [par. 6-10 -
*
10.00 V]
6-22
VLT AQUA 12-Pulse High Power Instruction Manual
Function:
Select the timeout function. The function set in
6-01 Live Zero Timeout Function will be
activated if the input signal on terminal 53 or
54 is below 50% of the value in 6-10 Terminal
53 Low Voltage, 6-12 Terminal 53 Low Current,
6-20 Terminal 54 Low Voltage or 6-22 Terminal
54 Low Current for a time period defined in
6-00 Live Zero Timeout Time. If several timeouts
occur simultaneously, the adjustable frequency
drive prioritizes the timeout functions as
follows:
1. 6-01 Live Zero Timeout Function
2. 8-04 Control Timeout Function
The output frequency of the adjustable
frequency drive can be:
•
[1] frozen at the present value
•
[2] overruled to stop
•
[3] overruled to Jog Speed
•
[4] overruled to max. speed
•
[5] overruled to stop with subsequent
trip
Function:
Enter the low voltage value. This analog
input scaling value should correspond to
the low reference/feedback value set in
6-14 Terminal 53 Low Ref./Feedb. Value.
Function:
Enter the high voltage value. This
analog input scaling value should
correspond to the high reference/
feedback value set in 6-15 Terminal 53
High Ref./Feedb. Value.
MG.20.Y1.22 - VLT
6-14 Terminal 53 Low Ref./Feedb. Value
Range:
0.000 N/A [-999999.999 -
*
999999.999 N/A]
6-15 Terminal 53 High Ref./Feedb. Value
Range:
50.000 N/A [-999999.999 -
*
999999.999 N/A]
6-20 Terminal 54 Low Voltage
Range:
0.07 V [0.00 - par.
*
6-21 V]
6-21 Terminal 54 High Voltage
Range:
10.00 V [par. 6-20 -
*
10.00 V]
6-24 Terminal 54 Low Ref./Feedb. Value
Range:
0.000 N/A [-999999.999 -
*
999999.999 N/A]
6-25 Terminal 54 High Ref./Feedb. Value
Range:
100.000 [-999999.999 -
N/A 999999.999 N/A]
*
®
is a registered Danfoss trademark
Function:
Enter the analog input scaling
value that corresponds to the
low voltage/low current set in
6-10 Terminal 53 Low Voltage
and 6-12 Terminal 53 Low
Current.
Function:
Enter the analog input scaling
value that corresponds to the
high voltage/high current
value set in 6-11 Terminal 53
High Voltage and 6-13 Terminal
53 High Current.
Function:
Enter the low voltage value. This analog
input scaling value should correspond to
the low reference/feedback value, set in
6-24 Terminal 54 Low Ref./Feedb. Value.
Function:
Enter the high voltage value. This
analog input scaling value should
correspond to the high reference/
feedback value set in 6-25 Terminal 54
High Ref./Feedb. Value.
Function:
Enter the analog input scaling
value that corresponds to the
low voltage/low current value
set in 6-20 Terminal 54 Low
Voltage and 6-22 Terminal 54
Low Current.
Function:
Enter the analog input scaling
value that corresponds to the
high voltage/high current
value set in 6-21 Terminal 54
High Voltage and
6-23 Terminal 54 High Current.
