How to Install
Figure 4.3 Rectifier Cabinet, unit sizes 61, 62, 63 and 64.
1)
12-pulse rectifier module
2)
AUX Fan
100
101
102
103
L1
L2
L1
L2
3)
Line Fuses F10/F12 (6 pieces)
VLT AQUA 12-Pulse High Power Instruction Manual
1
4)
Line
R1
S1
T1
L1-1 L2-1 L3-1 L1-2 L2-2
5)
DC Bus Connections for Common DC Bus
DC+ DC-
6)
DC Bus Connections for Common DC Bus
DC+ DC-
®
MG.20.Y1.22 - VLT
is a registered Danfoss trademark
2
3
4
R2
S2
T2
L3-2
4
4
4-5
