Special Functions 14 - Danfoss VLT AQUA Drive FC 200 Instruction Manual

How to program the adjustab...

6.3.13 Special Functions 14-**

Par. No. Parameter description
#
14-0* Inverter Switching
14-00 Switching Pattern
14-01 Switching Frequency
14-03 Overmodulation
14-04 PWM Random
14-1* Mains On/Off
14-10 Line Failure
14-11 AC Line Voltage at Line Fault
6 6
14-12 Function at Line Imbalance
14-2* Reset Functions
14-20 Reset Mode
14-21 Automatic Restart Time
14-22 Operation Mode
14-23 Typecode Setting
14-25 Trip Delay at Torque Limit
14-26 Trip Delay at Inverter Fault
14-28 Production Settings
14-29 Service Code
14-3* Current Limit Ctrl.
14-30 Current Lim Ctrl, Proportional Gain
14-31 Current Lim Ctrl, Integration Time
14-4* Energy Optimizing
14-40 VT Level
14-41 AEO Minimum Magnetization
14-42 Minimum AEO Frequency
14-43 Motor Cos-Phi
14-5* Environment
14-50 RFI Filter
14-52 Fan Control
14-53 Fan Monitor
14-55 Output Filter
14-59 Actual Number of Inverter Units
14-6* Auto Derate
14-60 Function at Overtemperature
14-61 Function at Inverter Overload
14-62 Inv. Overload Derate Current
14-8* Options
14-80 Option Supplied by External 24VDC
