How to program the adjustab...
Group no. Parameter group:
K-## Keypad Set-Up
F-## Fundamental Parameters
E-## Digital In/Out
C-## Frequency Control Functions
P-## Motor Data
H-## High Perf Parameters
AN-## Analog In/Out
SP-## Special Functions
O-## Options / Comms
AO-## Analog I/O Option
DN-## DeviceNet
PB-## Profibus
LN-## LonWorks
BN-## BACnet
ID-## Drive Information
DR-## Data Readouts
LG-## Logs & I/O Opt. Status
AP-## HVAC Appl. Param.
FB-## Fire/Bypass Operation
EN-## EtherNet
T-## Timed Functions
CL-## PID Closed-loop
XC-## Ext. PID Closed-loop
PC-## Pump Controller
LC-## Logic Controller
B-## Braking Functions
Table 6.4 Parameter groups.
Choose a parameter group from the main menu and press
[OK]. Then further select the parameter sub-groups by
using the up and down arrows and then press [OK].
The middle section of the keypad display shows the
parameters. Press [OK] to select the parameters; the display
now shows the selected parameter's value.
6.2 Commonly Used Parameters -
Explanations

6.2.1 Main Menu

The main menu includes all available parameters in the
®
VLT AQUA Drive FC 200 adjustable frequency drive.
All parameters are grouped logically with a group name
indicating the function of the parameter group.
All parameters are listed by name and number in the
section Parameter Options in this Instruction Manual.
All parameters included in the quick menus (Q1, Q2, Q3,
Q5 and Q6) can be found in the following.
Some of the most commonly used parameters for VLT
AQUA Drive applications are also explained in the
following section.
For a detailed explanation of all parameters, please refer to
®
the VLT AQUA Drive Programming Guide MG.20.OX.YY
which is available at www.danfoss.com or by ordering it
from the local Danfoss office.
VLT AQUA 12-Pulse High Power Instruction Manual
Parameters related to the fundamental functions of the ,
function of the LCP buttons and configuration of the LCP
display.
0-01 Language
Option:
[0]
[1]
[2]
[3]
[4]
[5]
[6]
[7]
[10] Chinese
[20] Finnish
[22] English US
[27] Greek
[28] Portuguese
[36] Slovenian
[39] Korean
[40] Japanese
[41] Turkish
[42] Traditional
[43] Bulgarian
[44] Serbian
[45] Romanian
[46] Hungarian
[47] Czech
[48] Polish
[49] Russian
[50] Thai
[51] Bahasa
0-20 Display Line 1.1 Small
Option:
®
[0]
[953]
®
MG.20.Y1.22 - VLT is a registered Danfoss trademark
Function:
Defines the language to be used in the
display.
The adjustable frequency drive can be
delivered with 4 different language
packages. English and German are
included in all packages. English cannot
be erased or manipulated.
English Part of Language packages 1 - 4
*
German Part of Language packages 1 - 4
French Part of Language package 1
Danish Part of Language package 1
Spanish Part of Language package 1
Italian Part of Language package 1
Swedish Part of Language package 1
Dutch Part of Language package 1
Language package 2
Part of Language package 1
Part of Language package 4
Part of Language package 4
Part of Language package 4
Part of Language package 3
Part of Language package 2
Part of Language package 2
Part of Language package 4
Part of Language package 2
Chinese
Part of Language package 3
Part of Language package 3
Part of Language package 3
Part of Language package 3
Part of Language package 3
Part of Language package 4
Part of Language package 3
Part of Language package 2
Part of Language package 2
Indonesian
Function:
Select a variable for display in line
1, left position.
None No display value selected
Profibus Warning Displays Profibus communication
Word warnings.
