Mechanical Installation
Terminal locations - Rectifier ()
Figure 3.13 Terminal locations - Rectifier (left side, front and right side view). The connector plate is 1.65 in [42 mm] below .0 level.
1) Load share Terminal (-)
2) Ground bar
3) Load share Terminal (+)
VLT AQUA 12-Pulse High Power Instruction Manual
239.6 [ 9.43 ]
R2/L12 91-1 S2/L22 92-1 T2/L32
160.0 [ 6.30 ]
91
R1/L11 S1/L21 92 T1/L31 93
56.6 [ 2.23 ]
0.0 [ 0.00 ]
®
MG.20.Y1.22 - VLT is a registered Danfoss trademark
U/T1 96 V/T2 97 W/T3 98
93-1
1
3 3
3-11
