Par. No. Parameter description
#
21-5* Ext. CL 3 Ref./Fb.
21-50 Ext. 3 Ref./Feedback Unit
21-51 Ext. 3 Minimum Reference
21-52 Ext. 3 Maximum Reference
21-53 Ext. 3 Reference Source
21-54 Ext. 3 Feedback Source
21-55 Ext. 3 Setpoint
21-57 Ext. 3 Reference [Unit]
21-58 Ext. 3 Feedback [Unit]
6 6 21-59 Ext. 3 Output [%]
21-6* Ext. CL 3 PID
21-60 Ext. 3 Normal/Inverse Control
21-61 Ext. 3 Proportional Gain
21-62 Ext. 3 Integral Time
21-63 Ext. 3 Differentiation Time
21-64 Ext. 3 Dif. Gain Limit
6-58
VLT AQUA 12-Pulse High Power Instruction Manual
Default value
[0] All set-ups
0.000 ExtPID3Unit All set-ups
100.000 ExtPID3Unit All set-ups
[0] No function All set-ups
[0] No function All set-ups
0.000 ExtPID3Unit All set-ups
0.000 ExtPID3Unit All set-ups
0.000 ExtPID3Unit All set-ups
0 % All set-ups
[0] Normal All set-ups
0.50 N/A All set-ups
20.00 s All set-ups
0.00 s All set-ups
5.0 N/A All set-ups
®
MG.20.Y1.22 - VLT is a registered Danfoss trademark
4 set-up Change
during sion index
operation
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
Conver- Type
- Uint8
-3 Int32
-3 Int32
- Uint8
- Uint8
-3 Int32
-3 Int32
-3 Int32
0 Int32
- Uint8
-2 Uint16
-2 Uint32
-2 Uint16
-1 Uint16
