6.3.10 Profibus 9-**
Par. No.
Parameter description
#
9-00
Setpoint
9-07
Actual Value
9-15
PCD Write Configuration
9-16
PCD Read Configuration
9-18
Node Address
9-22
Message Selection
9-23
Parameters for Signals
9-27
Parameter Edit
9-28
Process Control
9-44
Error Message Counter
9-45
Fault Code
9-47
Fault Number
9-52
Error Counter
9-53
Profibus Warning Word
9-63
Actual Baud Rate
9-64
Device Identification
9-65
Profile Number
9-67
Control Word 1
9-68
Status Word 1
9-71
Profibus Save Data Values
9-72
ProfibusDriveReset
9-80
Defined Parameters (1)
9-81
Defined Parameters (2)
9-82
Defined Parameters (3)
9-83
Defined Parameters (4)
9-84
Defined Parameters (5)
9-90
Changed Parameters (1)
9-91
Changed Parameters (2)
9-92
Changed Parameters (3)
9-93
Changed Parameters (4)
9-94
Changed Parameters (5)
VLT AQUA 12-Pulse High Power Instruction Manual
Default value
4 set-up
0 N/A
All set-ups
0 N/A
All set-ups
ExpressionLimit
2 set-ups
ExpressionLimit
2 set-ups
126 N/A
1 set-up
[108] PPO 8
1 set-up
0
All set-ups
[1] Enabled
2 set-ups
[1] Enable cyclic
master
2 set-ups
0 N/A
All set-ups
0 N/A
All set-ups
0 N/A
All set-ups
0 N/A
All set-ups
0 N/A
All set-ups
[255] No baud rate
found
All set-ups
0 N/A
All set-ups
0 N/A
All set-ups
0 N/A
All set-ups
0 N/A
All set-ups
[0] Off
All set-ups
[0] No action
1 set-up
0 N/A
All set-ups
0 N/A
All set-ups
0 N/A
All set-ups
0 N/A
All set-ups
0 N/A
All set-ups
0 N/A
All set-ups
0 N/A
All set-ups
0 N/A
All set-ups
0 N/A
All set-ups
0 N/A
All set-ups
®
MG.20.Y1.22 - VLT
is a registered Danfoss trademark
Change during
Conver-
operation
sion index
TRUE
0
FALSE
0
TRUE
-
TRUE
-
TRUE
0
TRUE
-
TRUE
-
FALSE
-
FALSE
-
TRUE
0
TRUE
0
TRUE
0
TRUE
0
TRUE
0
TRUE
-
TRUE
0
TRUE
0
TRUE
0
TRUE
0
TRUE
-
FALSE
-
FALSE
0
FALSE
0
FALSE
0
FALSE
0
FALSE
0
FALSE
0
FALSE
0
FALSE
0
FALSE
0
FALSE
0
Type
Uint16
Uint16
Uint16
Uint16
Uint8
Uint8
Uint16
Uint16
6
6
Uint8
Uint16
Uint16
Uint16
Uint16
V2
Uint8
Uint16
OctStr[2]
V2
V2
Uint8
Uint8
Uint16
Uint16
Uint16
Uint16
Uint16
Uint16
Uint16
Uint16
Uint16
Uint16
6-47
