How to Install
Figure 4.5 Inverter Cabinet, unit sizes 62 and 64
1) External Temperature Monitoring
2) AUX Relay
01 02 03
04 05 06
3) NAMUR
4) AUX Fan
100 101 102 103
L1 L2 L1 L2
5) Brake
-R +R
81 82
VLT AQUA 12-Pulse High Power Instruction Manual
1
3
7
4, 8, 9
5
FASTENER TORQUE: M10 19 Nm (14 FT-LB) FASTENER TORQUE: M10 19 Nm (14 FT-LB)
U/T1 96 V/T2 97 W/T3 98 U/T1 96 V/T2 97
6
6) Motor
7) NAMUR Fuse. See fuse tables for part numbers
8) Fan Fuses. See fuse tables for part numbers
9) SMPS Fuses. See fuse tables for part numbers
®
MG.20.Y1.22 - VLT is a registered Danfoss trademark
2
FASTENER TORQUE: M10 19 Nm (14 FT-LB)
W/T3 98 U/T1 96 V/T2 97 W/T3 98
U V W
96 97 98
T1 T2 T3
4 4
