Troubleshooting
No. Description
1 10 Volts low
2 Live zero error
3 No motor
4 Mains phase loss
5 DC link voltage high
6 DC link voltage low
7 DC overvoltage
8 DC undervoltage
9 Inverter overloaded
10 Motor ETR overtemperature
11 Motor thermistor over-temperature
12 Torque limit
13 Overcurrent
14 Ground fault
15 Hardware mismatch
16 Short Circuit
17 Control word timeout
23 Internal Fan Fault
24 External Fan Fault
29 Drive overtemperature
30 Motor phase U missing
31 Motor phase V missing
32 Motor phase W missing
33 Inrush fault
8 8
34 Fieldbus communication fault
36 Mains failure
38 Internal fault
39 Heatsink sensor
40 Overload of Digital Output Terminal 27
41 Overload of Digital Output Terminal 29
42 Overload of Digital Output On X30/6 (OPCGPIO)
42 Overload of Digital Output On X30/7 (OPCGPIO)
46 Pwr. card supply
47 24 V supply low
48 1.8 V supply low
49 Speed limit
50 Auto Tune calibration failed
51 Auto Tune check U
52 Auto Tune low I
53 Auto Tune motor too big
54 Auto Tune motor too small
55 Auto Tune parameter out of range
56 Auto Tune interrupted by user
57 Auto Tune timeout
58 Auto Tune internal fault
59 Current limit
61 Tracking Error
62 Output Frequency at Maximum Limit
65 Control Board Overtemperature
66 Heat sink Temperature Low
67 Option Configuration has Changed
68 Safe Stop Activated
69 Pwr. Card Temp
70 Illegal Drive configuration
72 Dangerous Failure
73 Safe Stop Auto Restart
77 Reduced power mode
79 Illegal PS config
80 Drive Restored to Factory Settings
85 Profibus/Profisafe Error
92 No-Flow
93 Dry Pump
94 End of Curve
95 Broken Belt
96 Start Delayed
97 Stop Delayed
98 Clock Fault
Table 8.1 Alarm/Warning Code List
