D Microphone connection
A microphone connector is available on the main unit front
panel. Connect the supplied microphone connector as illus-
trated below.
Controller
Main unit
Attach the supplied microphone connector plate after the mi-
crophone connection, otherwise the controller will easily
dropped off when the microphone cable is pulled during sin-
gle body installation.
D Controller's attachment
You can attach the controller of the IC-2820H in one of 2
methods.
• Example 1
Microphone
• Example 2
QUICK REFERENCE GUIDE
IV
