• PERSONAL CALLS
This display appears when you are called with your ID code
and the calling station's ID code is 123.
"CP" and "
• GROUP CALLS
This display appears when you are called with the group
code, 888, and 888 has been programmed into code channel
C5.
Code channel
• ERROR INFORMATION
When the transceiver receives an incomplete code, "E" and
previously received code appear.
Previously received code.
During channel number indication (described on page 16)
To use these functions in channel number indication, the
pager/code squelch setting must be programmed with other
memory contents before selecting channel number indication.
" blink.
PAGER/CODE SQUELCH
I Code squelch
When using code squelch you will only receive calls from sta-
tions which know your ID or group code. A 3-digit code is sent
each time [PTT] is pushed in order to open the receiving sta-
tion's code squelch prior to voice transmission.
q Set the operating frequency.
• Set the volume and squelch to the desired level as in normal op-
eration.
w Push [F F •
] to display the function guide.
w Enter "PGR/C-SQL" set item in "DUP/TONE" set mode,
then push [MAIN•BAND].
• Rotate [DIAL] to select "C-SQL," if "PGR" or "OFF" appears.
w Enter "PGR CODE" set item in "DUP/TONE" set mode,
then push [MAIN•BAND].
e Select the desired transmit code channel:
➥ Rotate [DIAL] to select the desired code channel.
➥ Push [F F •
] to return to previous mode.
• "C-SQL." indication apper.
r Operate the transceiver in the normal way (push [PTT] to
transmit; release [PTT] to receive).
t To cancel the code squelch, Enter "PGR/C-SQL" set item,
then rotate [DIAL] to select "OFF"
• 100 MHz digit shows "1" when the function is cancelled.
