3.2.1
Additional Cable Information
In addition to the above specifications, the information provided below may be useful:
3.2.1.1
Data Cables
0.5mm² cable - 2 twisted pair
Reference: TX®(I) 2X2X0.5
Type: Marine Grade – Low Smoke, Halogen Free, Fire Retardant
Approval: ABS, BV, DNV, GL, LRS or RINA
0.5mm² cable - 4 twisted pair
Reference: TX®(I) 4X2X0.5
Type: Marine Grade – Low Smoke, Halogen Free, Fire Retardant
Approval: ABS, BV, DNV, GL, LRS or RINA
0.75mm² cable - 2 twisted pair
Reference: TX®(I) 2X2X0.75
Type: Marine Grade – Low Smoke, Halogen Free, Fire Retardant
Approval: ABS, BV, DNV, GL, LRS or RINA
0.75mm² cable - 4 twisted pair
Reference: TX®(I) 4X2X0.75
Type: Marine Grade – Low Smoke, Halogen Free, Fire Retardant
Approval: ABS, BV, DNV, GL, LRS or RINA
3.2.1.2
Power Supply Cable
3x1.5mm² cable
Reference: MPRX® 3x1.5
Type: Marine Grade– Low Smoke, Halogen Free, Fire Retardant
Approval: ABS, BV, DNV, GL, LRS or RINA
3.2.1.3
Video Cable
75 ohm Coaxial cable - RG11 for cable lengths > 30m
Reference: FLAMEX RG11AU
Type: Marine Grade – Low Smoke, Halogen Free, Fire Retardant
75 ohm Coaxial cable – RG6 for cable lengths < 30m
Reference: FLAMEX RG11AU
Type: Marine Grade – Low Smoke, Halogen Free, Fire Retardant
Approval: ABS, BV, DNV, GL, LRS or RINA
3.2.1.4
FRM Cable
FTP Category 5e cable
Reference: LSZH 4PR 24AWG FF5100 021807 M OF45264
Type: Marine Grade – Low Smoke, Halogen Free, Fire Retardant
Approval: ABS, BV, DNV, GL, LRS or RINA
VDR-100G3/G3S Installation Manual
Chapter 3: Installation Planning Overview, Rev. 1.1
3-2
06/10/2008
